CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG87
2630 First Character of RRTD 4 - RTD #2 Name 32 127 1 - F1 ’R’
↓↓
2633 8th Character of RRTD 4 - RTD #2 Name 32 127 1 - F1 " "
... Reserved
RRTD 4 – RTD #3
2640 RRTD 4 - RTD #3 Application 0 4 1 - F121 0
2641 RRTD 4 - RTD #3 High Alarm 0 2 1 - F115 0
2642 RRTD 4 - RTD #3 High Alarm Relays 0 7 1 - F113 2
2643 RRTD 4 - RTD #3 High Alarm Level 1 200 1 °C F1 130
2644 RRTD 4 - RTD #3 Alarm 0 2 1 - F115 0
2645 RRTD 4 - RTD #3 Alarm Relays 0 7 1 - F113 1
2646 RRTD 4 - RTD #3 Alarm Level 1 200 1 °C F1 130
2647 Record RRTD 4 - RTD #3 Alarms as Events 0 1 1 - F103 0
2648 RRTD 4 - RTD #3 Trip 0 2 1 - F115 0
2649 Enable RRTD 4 - RTD #3 Trip Voting 0 13 1 - F122 1
264A RRTD 4 - RTD #3 Trip Relays 0 7 1 - F111 1
264B RRTD 4 - RTD #3 Trip Level 1 200 1 °C F1 130
264C RRTD 4 - RTD #3 RTD Type 0 3 1 - F120 0
2650 First Character of RRTD 4 - RTD # Name 32 127 1 - F1 ’R’
↓↓
2653 8th Character of RRTD 4 - RTD #3 Name 32 127 1 - F1 " "
... Reserved
RRTD 4 – RTD #4
2660 RRTD 4 - RTD #4 Application 0 4 1 - F121 0
2661 RRTD 4 - RTD #4 High Alarm 0 2 1 - F115 0
2662 RRTD 4 - RTD #4 High Alarm Relays 0 7 1 - F113 2
2663 RRTD 4 - RTD #4 High Alarm Level 1 200 1 °C F1 130
2664 RRTD 4 - RTD #4 Alarm 0 2 1 - F115 0
2665 RRTD 4 - RTD #4 Alarm Relays 0 7 1 - F113 1
2666 RRTD 4 - RTD #4 Alarm Level 1 200 1 °C F1 130
2667 Record RRTD 4 - RTD #4 Alarms as Events 0 1 1 - F103 0
2668 RRTD 4 - RTD #4 Trip 0 2 1 - F115 0
2669 Enable RRTD 4 - RTD #4 Trip Voting 0 13 1 - F122 1
266A RRTD 4 - RTD #4 Trip Relays 0 7 1 - F111 1
266B RRTD 4 - RTD #4 Trip Level 1 200 1 °C F1 130
266C RRTD 4 - RTD #4 RTD Type 0 3 1 - F120 0
2670 First Character of RRTD 4 - RTD #4 Name 32 127 1 - F1 ’R’
↓↓
2673 8th Character of RRTD 4 - RTD #4 Name 32 127 1 - F1 " "
... Reserved
RRTD 4 – RTD #5
2680 RRTD 4 - RTD #5 Application 0 4 1 - F121 0
2681 RRTD 4 - RTD #5 High Alarm 0 2 1 - F115 0
2682 RRTD 4 - RTD #5 High Alarm Relays 0 7 1 - F113 2
2683 RRTD 4 - RTD #5 High Alarm Level 1 200 1 °C F1 130
2684 RRTD 4 - RTD #5 Alarm 0 2 1 - F115 0
2685 RRTD 4 - RTD #5 Alarm Relays 0 7 1 - F113 1
2686 RRTD 4 - RTD #5 Alarm Level 1 200 1 °C F1 130
2687 Record RRTD 4 - RTD #5 Alarms as Events 0 1 1 - F103 0
2688 RRTD 4 - RTD #5 Trip 0 2 1 - F115 0
2689 Enable RRTD 4 - RTD #5 Trip Voting 0 13 1 - F122 1
268A RRTD 4 - RTD #5 Trip Relays 0 7 1 - F111 1
268B RRTD 4 - RTD #5 Trip Level 1 200 1 °C F1 130
268C RRTD 4 - RTD #5 RTD Type 0 3 1 - F120 0
2690 First Character of RRTD 4 - RTD #5 Name 32 127 1 - F1 ’R’
↓↓
2693 8th Character of RRTD 4 - RTD #5 Name 32 127 1 - F1 " "
... Reserved
Table CG–10: MEMORY MAP (Sheet 42 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
