CG84 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
2489 Enable RRTD 3 - RTD #5 Trip Voting 0 13 1 - F122 1
248A RRTD 3 - RTD #5 Trip Relays 0 7 1 - F111 1
248B RRTD 3 - RTD #5 Trip Level 1 200 1 °C F1 130
248C RRTD 3 - RTD #5 RTD Type 0 3 1 - F120 0
2490 First Character of RRTD 3 - RTD #5 Name 32 127 1 - F1 ’R’
↓↓
2493 8th Character of RRTD 3 - RTD #5 Name 32 127 1 - F1 " "
... Reserved
RRTD 3 – RTD #6
24A0 RRTD 3 - RTD #6 Application 0 4 1 - F121 0
24A1 RRTD 3 - RTD #6 High Alarm 0 2 1 - F115 0
24A2 RRTD 3 - RTD #6 High Alarm Relays 0 7 1 - F113 1
24A3 RRTD 3 - RTD #6 High Alarm Level 1 200 1 °C F1 130
24A4 RRTD 3 - RTD #6 Alarm 0 2 1 - F115 0
24A5 RRTD 3 - RTD #6 Alarm Relays 0 7 1 - F113 1
24A6 RRTD 3 - RTD #6 Alarm Level 1 200 1 °C F1 130
24A7 Record RRTD 3 - RTD #6 Alarms as Events 0 1 1 - F103 0
24A8 RRTD 3 - RTD #6 Trip 0 2 1 - F115 0
24A9 Enable RRTD 3 - RTD #6 Trip Voting 0 13 1 - F122 1
24AA RRTD 3 - RTD #6 Trip Relays 0 7 1 - F111 1
24AB RRTD 3 - RTD #6 Trip Level 1 200 1 °C F1 130
24AC RRTD 3 - RTD #6 RTD Type 0 3 1 - F120 0
24B0 First Character of RRTD 3 - RTD #6 Name 32 127 1 - F1 ’R’
↓↓
24B3 8th Character of RRTD 3 - RTD #6 Name 32 127 1 - F1 " "
... Reserved
RRTD 3 – RTD #7
24C0 RRTD 3 - RTD #7 Application 0 4 1 - F121 0
24C1 RRTD 3 - RTD #7 High Alarm 0 2 1 - F115 0
24C2 RRTD 3 - RTD #7 High Alarm Relays 0 7 1 - F113 2
24C3 RRTD 3 - RTD #7 High Alarm Level 1 200 1 °C F1 130
24C4 RRTD 3 - RTD #7 Alarm 0 2 1 - F115 0
24C5 RRTD 3 - RTD #7 Alarm Relays 0 7 1 - F113 1
24C6 RRTD 3 - RTD #7 Alarm Level 1 200 1 °C F1 130
24C7 Record RRTD 3 - RTD #7 Alarms as Events 0 1 1 - F103 0
24C8 RRTD 3 - RTD #7 Trip 0 2 1 - F115 0
24C9 Enable RRTD 3 - RTD #7 Trip Voting 0 13 1 - F122 1
24CA RRTD 3 - RTD #7 Trip Relays 0 7 1 - F111 1
24CB RRTD 3 - RTD #7 Trip Level 1 200 1 °C F1 130
24CC RRTD 3 - RTD #7 RTD Type 0 3 1 - F120 0
24D0 First Character of RRTD 3 - RTD #7 Name 32 127 1 - F1 ’R’
↓↓
24D3 8th Character of RRTD 3 - RTD #7 Name 32 127 1 - F1 " "
... Reserved
RRTD 3 – RTD #8
24E0 RRTD 3 - RTD #8 Application 0 4 1 - F121 0
24E1 RRTD 3 - RTD #8 High Alarm 0 2 1 - F115 0
24E2 RRTD 3 - RTD #8 High Alarm Relays 0 7 1 - F113 2
24E3 RRTD 3 - RTD #8 High Alarm Level 1 200 1 °C F1 130
24E4 RRTD 3 - RTD #8 Alarm 0 2 1 - F115 0
24E5 RRTD 3 - RTD #8 Alarm Relays 0 7 1 - F113 1
24E6 RRTD 3 - RTD #8 Alarm Level 1 200 1 °C F1 130
24E7 Record RRTD 3 - RTD #8 Alarms as Events 0 1 1 - F103 0
24E8 RRTD 3 - RTD #8 Trip 0 2 1 - F115 0
24E9 Enable RRTD 3 - RTD #8 Trip Voting 0 13 1 - F122 1
24EA RRTD 3 - RTD #8 Trip Relays 0 7 1 - F111 1
24EB RRTD 3 - RTD #8 Trip Level 1 200 1 °C F1 130
24EC RRTD 3 - RTD #8 RTD Type 0 3 1 - F120 0
24F0 First Character of RRTD 3 - RTD #8 Name 32 127 1 - F1 ’R’
Table CG–10: MEMORY MAP (Sheet 39 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
