CG106 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
F103
Unsigned 16 bit integer OFF/ON OR NO/YES SELECTION
0Off / No
1On / Yes
F104
Unsigned 16 bit integer GROUND CT TYPE
0None
11 A Secondary
25 A Secondary
3 Multilin CT 50/0.025
F105
Unsigned 16 bit integer CT TYPE
0None
11 A Secondary
25 A Secondary
F106
Unsigned 16 bit integer VOLTAGE TRANSFORMER CONNECTION TYPE
0None
1Open Delta
2Wye
F107
Unsigned 16 bit integer NOMINAL FREQUENCY
060 Hz
150 Hz
2Variable
F108
Unsigned 16 bit integer REDUCED VOLTAGE STARTING TRANSITION ON
0 Current Only
1 Current or Timer
2 Current and Timer
F109
Unsigned 16 bit integer STARTER STATUS SWITCH
0Starter Aux a (52a)
1Starter Aux b (52b)
F110
Unsigned 16 bit integer EMERGENCY RESTART SWITCH INPUT FUNCTION
0Off
1 Emergency Switch
2 General Switch
3 Digital Counter
4 Waveform Capture
5 DeviceNet Control
6
Speed Switch
1
7 Reserved
Table CG–11: Memory Map Data Formats (Sheet 4 of 27)
CODE TYPE DEFINITION

GE 369 Specifications

General

Current Rating	5A
Frequency	50/60 Hz
Mounting	Panel Mount
Protection Functions	Overcurrent, Undervoltage
Type	Digital protective relay
Operating Temperature	-20°C to 60°C
