CG62 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
DIFFERENTIAL
1370
1st & 2nd Character of Differential Switch
Name
32 127 1 - F22 ’G’
1380 General Differential Switch Type 0 1 1 - F116 0
1381
General Differential Switch Block Input
From Start
0 5000 1 s F1 0
1382 General Differential Switch Alarm 0 2 1 - F115 0
1383 General Differential Switch Alarm Relays 0 7 1 - F113 1
1384 General Differential Switch Alarm Delay 1 50000 1 100ms F2 50
1385 General Differential Switch Alarm Events 0 1 1 - F103 0
1386 General Differential Switch Trip 0 2 1 - F115 0
1387 General Differential Switch Trip Relays 0 7 1 - F111 1
1388 General Differential Switch Trip Delay 1 50000 1 100ms F2 50
1389 Differential Switch Assignable Function 0 7 1 - F157 0
138A Assign Differential Switch Trip Relays 0 7 1 - F111 1
... Reserved
SPEED
13A0
1st & 2nd Character of Speed Switch
Name
32 127 1 - F22 ’G’
13B0 General Speed Switch Type 0 1 1 - F116 0
13B1
General Speed Switch Block Input from
Start
0 5000 1 s F1 0
13B2 General Speed Switch Alarm 0 2 1 - F115 0
13B3 General Speed Switch Alarm Relays 0 7 1 - F113 1
13B4 General Speed Switch Alarm Delay 1 50000 1 100ms F2 50
13B5 General Speed Switch Alarm Events 0 1 1 - F103 0
13B6 General Speed Switch Trip 0 2 1 - F115 0
13B7 General Speed Switch Trip Relays 0 7 1 - F111 1
13B8 General Speed Switch Trip Delay 1 50000 1 100ms F2 50
13B9 Speed Switch Assignable Function 0 7 1 - F158 0
13BA Speed Switch Delay 5 1000 5 100ms F2 20
13BB Assign Speed Switch Trip Relays 0 7 1 - F111 1
... Reserved
RESET
13D0
1st & 2nd Character of Reset Switch
Name
32 127 1 - F22 ’G’
13E0 General Reset Switch Type 0 1 1 - F116 0
13E1
General Reset Switch Block Input From
Start
0 5000 1 s F1 0
13E2 General Reset Switch Alarm 0 2 1 - F115 0
13E3 General Reset Switch Alarm Relays 0 7 1 - F113 1
13E4 General Reset Switch Alarm Delay 1 50000 1 100ms F2 50
13E5 General Reset Switch Alarm Events 0 1 1 - F103 0
13E6 General Reset Switch Trip 0 2 1 - F115 0
13E7 General Reset Switch Trip Relays 0 7 1 - F111 1
13E8 General Reset Switch Trip Delay 1 50000 1 100ms F2 50
13E9 Reset Switch Assignable Function 0 7 1 - F160 0
... Reserved
SPARE
1400
1st & 2nd Character of Spare Switch
Name
32 127 1 - F22 ’G’
1410 General Spare Switch Type 0 1 1 - F116 0
1411
General Spare Switch Block Input From
Start
0 5000 1 s F1 0
1412 General Spare Switch Alarm 0 2 1 - F115 0
1413 General Spare Switch Alarm Relays 0 7 1 - F113 1
1414 General Spare Switch Alarm Delay 1 50000 1 100ms F2 50
1415 General Spare Switch Alarm Events 0 1 1 - F103 0
1416 General Spare Switch Trip 0 1 1 - F115 0
1417 General Spare Switch Trip Relays 0 7 1 - F111 1
1418 General Spare Switch Trip Delay 1 50000 1 100 ms F2 50
1419 Spare Switch Assignable Function 0 7 1 - F159 0
Table CG–10: MEMORY MAP (Sheet 17 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
