CG86 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
RRTD 3 – RTD #12
2560 RRTD 3 - RTD #12 Application 0 4 1 - F121 0
2561 RRTD 3 - RTD #12 High Alarm 0 2 1 - F115 0
2562 RRTD 3 - RTD #12 High Alarm Relays 0 7 1 - F113 2
2563 RRTD 3 - RTD #12 High Alarm Level 1 200 1 °C F1 130
2564 RRTD 3 - RTD #12 Alarm 0 2 1 - F115 0
2565 RRTD 3 - RTD #12 Alarm Relays 0 7 1 - F113 1
2566 RRTD 3 - RTD #12 Alarm Level 1 200 1 °C F1 130
2567
Record RRTD 3 - RTD #12 Alarms as
Events
0 1 1 - F103 0
2568 RRTD 3 - RTD #12 Trip 0 2 1 - F115 0
2569 Enable RRTD 3 - RTD #12 Trip Voting 0 13 1 - F122 1
256A RRTD 3 - RTD #12 Trip Relays 0 7 1 - F111 1
256B RRTD 3 - RTD #12 Trip Level 1 200 1 °C F1 130
256C RRTD 3 - RTD #12 RTD Type 0 3 1 - F120 0
2570 First Character of RRTD 3 - RTD #12 Name 32 127 1 - F1 ’R’
↓↓
2573 8th Character of RRTD 3 - RTD #12 Name 32 127 1 - F1 " "
... Reserved
RRTD 3 – OPEN RTD ALARM
2580 RRTD 3 - Open RTD Alarm 0 2 1 - F115 0
2581 RRTD 3 - Assign Alarm Relays 0 7 1 - F113 1
2582 RRTD 3 - Open RTD Alarm Events 0 1 1 - F103 0
RRTD 3 – SHORT/LOW TEMPERATURE RTD ALARM
2583 RRTD 3 - Short / Low Temp RTD Alarm 0 2 1 - F115 0
2584 RRTD 3 - Assign Alarm Relays 0 7 1 - F113 1
2585 RRTD 3 - Short / Low Temp Alarm Events 0 1 1 - F103 0
... Reserved - - - - - -
RRTD 4 – RTD #1
2600 RRTD 4 - RTD #1 Application 0 4 1 - F121 0
2601 RRTD 4 - RTD #1 High Alarm 0 2 1 - F115 0
2602 RRTD 4 - RTD #1 High Alarm Relays 0 7 1 - F113 2
2603 RRTD 4 - RTD #1 High Alarm Level 1 200 1 °C F1 130
2604 RRTD 4 - RTD #1 Alarm 0 2 1 - F115 0
2605 RRTD 4 - RTD #1 Alarm Relays 0 7 1 - F113 1
2606 RRTD 4 - RTD #1 Alarm Level 1 200 1 °C F1 130
2607 Record RRTD 4 - RTD #1 Alarms as Events 0 1 1 - F103 0
2608 RRTD 4 - RTD #1 Trip 0 2 1 - F115 0
2609 Enable RRTD 4 - RTD #1 Trip Voting 0 13 1 - F122 1
260A RRTD 4 - RTD #1 Trip Relays 0 7 1 - F111 1
260B RRTD 4 - RTD #1 Trip Level 1 200 1 °C F1 130
260C RRTD 4 - RTD #1 RTD Type 0 3 1 - F120 0
2610 First Character of RRTD 4 - RTD #1 Name 32 127 1 - F1 ’R’
↓↓
2613 8th Character of RRTD 4 - RTD #1 Name 32 127 1 - F1 " "
.... Reserved
RRTD 4 – RTD #2
2620 RRTD 4 - RTD #2 Application 0 4 1 - F121 0
2621 RRTD 4 - RTD #2 High Alarm 0 2 1 - F115 0
2622 RRTD 4 - RTD #2 High Alarm Relays 0 7 1 - F113 2
2623 RRTD 4 - RTD #2 High Alarm Level 1 200 1 °C F1 130
2624 RRTD 4 - RTD #2 Alarm 0 2 1 - F115 0
2625 RRTD 4 - RTD #2 Alarm Relays 0 7 1 - F113 1
2626 RRTD 4 - RTD #2 Alarm Level 1 200 1 °C F1 130
2627 Record RRTD 4 - RTD #2 Alarms as Events 0 1 1 - F103 0
2628 RRTD 4 - RTD #2 Trip 0 2 1 - F115 0
2629 Enable A Remote RTD #2 Trip Voting 0 13 1 - F122 1
262A RRTD 4 - RTD #2 Trip Relays 0 7 1 - F111 1
262B RRTD 4 - RTD #2 Trip Level 1 200 1 °C F1 130
262C RRTD 4 - RTD #2 RTD Type 0 3 1 - F120 0
Table CG–10: MEMORY MAP (Sheet 41 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
