CG94 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
2913 Digital Input 3 Alarm Relays 0 6 1 - F113 0
2914 Digital Input 3 Alarm Delay 1 50000 1 100ms F2 50
2915 Digital Input 3 Alarm Events 0 1 1 - F103 0
2916 Digital Input 3 Trip 0 2 1 - F115 0
2917 Digital Input 3 Trip Relays 0 6 1 - F111 0
2918 Digital Input 3 Trip Delay 1 50000 1 100ms F2 50
2919 Digital Input 3 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 2 – DIGITAL INPUT 2
2920
1st & 2nd Character of Digital Input 2
Name
32 127 1 - F22 ’GE’
↓↓
2925
11th & 12th Character of Digital Input 2
Name
32 127 1 - F22 ’GE’
2930 Digital Input 2 Type 0 1 1 - F116 0
2931 Reserved
2932 Digital Input 2 Alarm 0 2 1 - F115 0
2933 Digital Input 2 Alarm Relays 0 6 1 - F113 0
2934 Digital Input 2 Alarm Delay 1 50000 1 100ms F2 50
2935 Digital Input 2 Alarm Events 0 1 1 - F103 0
2936 Digital Input 2 Trip 0 2 1 - F115 0
2937 Digital Input 2 Trip Relays 0 6 1 - F111 0
2938 Digital Input 2 Trip Delay 1 50000 1 100ms F2 50
2939 Digital Input 2 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 2 – DIGITAL INPUT 5
2940
1st & 2nd Character of Digital Input 5
Name
32 127 1 - F22 ’GE’
↓↓
2945
11th & 12th Character of Digital Input 5
Name
32 127 1 - F22 ’GE’
2950 Digital Input 5 Type 0 1 1 - F116 0
2951 Reserved
2952 Digital Input 5 Alarm 0 2 1 - F115 0
2953 Digital Input 5 Alarm Relays 0 6 1 - F113 0
2954 Digital Input 5 Alarm Delay 1 50000 1 100ms F2 50
2955 Digital Input 5 Alarm Events 0 1 1 - F103 0
2956 Digital Input 5 Trip 0 2 1 - F115 0
2957 Digital Input 5 Trip Relays 0 6 1 - F111 0
2958 Digital Input 5 Trip Delay 1 50000 1 100ms F2 50
2959 Digital Input 5 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 2 – DIGITAL INPUT 4
2960
1st & 2nd Character of Digital Input 4
Name
32 127 1 - F22 ’GE’
↓↓
2965
11th & 12th Character of Digital Input 4
Name
32 127 1 - F22 ’GE’
2970 Digital Input 4 Type 0 1 1 - F116 0
2971 Reserved
2972 Digital Input 4 Alarm 0 2 1 - F115 0
2973 Digital Input 4 Alarm Relays 0 6 1 - F113 0
2974 Digital Input 4 Alarm Delay 1 50000 1 100ms F2 50
2975 Digital Input 4 Alarm Events 0 1 1 - F103 0
2976 Digital Input 4 Trip 0 2 1 - F115 0
2977 Digital Input 4 Trip Relays 0 6 1 - F111 0
2978 Digital Input 4 Trip Delay 1 50000 1 100ms F2 50
2979 Digital Input 4 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 2 – DIGITAL INPUT 1
2980
1st & 2nd Character of Digital Input 1
Name
32 127 1 - F22 ’GE’
Table CG–10: MEMORY MAP (Sheet 49 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
