CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG47
0024 Serial Number character 9 and 10 N/A N/A N/A ASCII F22 N/A
0025 Serial Number character 11 and 12 N/A N/A N/A ASCII F22 N/A
0026 Main Firmware Build Date N/A N/A N/A - F18 N/A
0028 Main Firmware Build Time N/A N/A N/A - F19 N/A
... Reserved - - - - - -
0040 Manufacturing Date 1995 2094 1 - F18 Jan.1,1999
... Reserved - - - - - -
SETPOINT ACCESS
0050 Keypad Access Level 0 1 1 N/A F162 0
0051 Comm Access Level 0 1 1 N/A F162 0
0052 Access Password Character 1 and 2 32 127 1 - F1 " "
0053 Access Password Character 3 and 4 32 127 1 - F1 " "
0054 Access Password Character 5 and 6 32 127 1 - F1 " "
0055 Access Password Character 7 and 8 32 127 1 - F1
0056 Encrypted Access Password 1 and 2 32 127 1 - F1 “AI”
0057 Encrypted Access Password 3 and 4 32 127 1 - F1 “KF”
0058 Encrypted Access Password 5 and 6 32 127 1 - F1 “BA”
0059 Encrypted Access Password 7 and 8 32 127 1 - F1 IK”
... Reserved - - - - - -
COMMANDS (ADDRESSES 0080 TO 00FB)
0080 Command Function Code 0 21 1 - F31 0
0081 Reserved
0082 RRTD 1 Command Function Code 0 4 1 - F31 0
0083 RRTD 2 Command Function Code 0 4 1 - F31 0
0084 RRTD 3 Command Function Code 0 4 1 - F31 0
0085 RRTD 4 Command Function Code 0 4 1 - F31 0
... Reserved
REAL TIME CLOCK
00F0 Time (2 words) valid time N/A - F19 -
00F2 Date (2 words) valid date N/A - F18 -
... Reserved
PROFIBUS COMMUNICATIONS
00FC Profibus Loss of Comms Enable 0 2 1 - F115 0 (Off)
00FD Profibus Loss of Comms Delay 25 1000 1 250 ms F2 25
00FE Assigned Profibus Loss of Comms Relay 0 15 1 - F169 0
00FF Profibus Cyclic Input Data Configuration 0 110 1 - F1 0
USER MAP (ADDRESSES 0100 TO 017F)
0100 User Map Value # 1 --- --- --- --- --- ---
↓↓
017C User Map Value # 125 --- --- --- --- --- ---
... Reserved
0180 User Map Address # 1 0 3FFF 1 hex F1 0
↓↓
01FC User Map Address # 125 0 3FFF 1 hex F1 0
... Reserved
ACTUAL VALUES (ADDRESSES 0200 TO 0FFF)
MOTOR STATUS
0200 Motor Status 0 4 1 - F133 0
0201 Motor Thermal Capacity Used 0 100 1 % F1 0
0202 Estimated Time to Trip on Overload -1 65500 1 s F20 -1
AUTORESTART
0203 Restart Attempts 0 20000 1 - F1 -
0204 Restart Total Delay 0 65535 1 sec. F1 -
0205 Restart In Progress 0 1 1 Y/N F1 -
0206 UVR Power Loss Time 0 40000 1 0.1 s F2 Read Only
MOTOR SPEED STATUS
0207 Motor Speed Status 0 2 1 N/A F186 0
... Reserved
Table CG–10: MEMORY MAP (Sheet 2 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
