CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG79
220C RRTD 2 - RTD #1 RTD Type 0 3 1 - F120 0
2210 First Character of RRTD 2 - RTD #1 Name 32 127 1 - F1 ’R’
↓↓
2213 8th Character of RRTD 2 - RTD #1 Name 32 127 1 - F1 " "
... Reserved
RRTD 2 – RTD #2
2220 RRTD 2 - RTD #2 Application 0 4 1 - F121 0
2221 RRTD 2 - RTD #2 High Alarm 0 2 1 - F115 0
2222 RRTD 2 - RTD #2 High Alarm Relays 0 7 1 - F113 2
2223 RRTD 2 - RTD #2 High Alarm Level 1 200 1 °C F1 130
2224 RRTD 2 - RTD #2 Alarm 0 2 1 - F115 0
2225 RRTD 2 - RTD #2 Alarm Relays 0 7 1 - F113 1
2226 RRTD 2 - RTD #2 Alarm Level 1 200 1 °C F1 130
2227 Record RRTD 2 - RTD #2 Alarms as Events 0 1 1 - F103 0
2228 RRTD 2 - RTD #2 Trip 0 2 1 - F115 0
2229 Enable A Remote RTD #2 Trip Voting 0 13 1 - F122 1
222A RRTD 2 - RTD #2 Trip Relays 0 7 1 - F111 1
222B RRTD 2 - RTD #2 Trip Level 1 200 1 °C F1 130
222C RRTD 2 - RTD #2 RTD Type 0 3 1 - F120 0
2230 First Character of RRTD 2 - RTD #2 Name 32 127 1 - F1 ’R’
↓↓
2233 8th Character of RRTD 2 - RTD #2 Name 32 127 1 - F1 " "
... Reserved
RRTD 2 – RTD #3
2240 RRTD 2 - RTD #3 Application 0 4 1 - F121 0
2241 RRTD 2 - RTD #3 High Alarm 0 2 1 - F115 0
2242 RRTD 2 - RTD #3 High Alarm Relays 0 7 1 - F113 2
2243 RRTD 2 - RTD #3 High Alarm Level 1 200 1 °C F1 130
2244 RRTD 2 - RTD #3 Alarm 0 2 1 - F115 0
2245 RRTD 2 - RTD #3 Alarm Relays 0 7 1 - F113 1
2246 RRTD 2 - RTD #3 Alarm Level 1 200 1 °C F1 130
2247 Record RRTD 2 - RTD #3 Alarms as Events 0 1 1 - F103 0
2248 RRTD 2 - RTD #3 Trip 0 2 1 - F115 0
2249 Enable RRTD 2 - RTD #3 Trip Voting 0 13 1 - F122 1
224A RRTD 2 - RTD #3 Trip Relays 0 7 1 - F111 1
224B RRTD 2 - RTD #3 Trip Level 1 200 1 °C F1 130
224C RRTD 2 - RTD #3 RTD Type 0 3 1 - F120 0
2250 First Character of RRTD 2 - RTD # Name 32 127 1 - F1 ’R’
↓↓
2253 8th Character of RRTD 2 - RTD #3 Name 32 127 1 - F1 " "
... Reserved
RRTD 2 – RTD #4
2260 RRTD 2 - RTD #4 Application 0 4 1 - F121 0
2261 RRTD 2 - RTD #4 High Alarm 0 2 1 - F115 0
2262 RRTD 2 - RTD #4 High Alarm Relays 0 7 1 - F113 2
2263 RRTD 2 - RTD #4 High Alarm Level 1 200 1 °C F1 130
2264 RRTD 2 - RTD #4 Alarm 0 2 1 - F115 0
2265 RRTD 2 - RTD #4 Alarm Relays 0 7 1 - F113 1
2266 RRTD 2 - RTD #4 Alarm Level 1 200 1 °C F1 130
2267 Record RRTD 2 - RTD #4 Alarms as Events 0 1 1 - F103 0
2268 RRTD 2 - RTD #4 Trip 0 2 1 - F115 0
2069 Enable RRTD 2 - RTD #4 Trip Voting 0 13 1 - F122 1
226A RRTD 2 - RTD #4 Trip Relays 0 7 1 - F111 1
226B RRTD 2 - RTD #4 Trip Level 1 200 1 °C F1 130
226C RRTD 2 - RTD #4 RTD Type 0 3 1 - F120 0
2270 First Character of RRTD 2 - RTD #4 Name 32 127 1 - F1 ’R’
↓↓
2273 8th Character of RRTD 2 - RTD #4 Name 32 127 1 - F1 " "
... Reserved
Table CG–10: MEMORY MAP (Sheet 34 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
