CG80 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
RRTD 2 – RTD #5
2280 RRTD 2 - RTD #5 Application 0 4 1 - F121 0
2281 RRTD 2 - RTD #5 High Alarm 0 2 1 - F115 0
2282 RRTD 2 - RTD #5 High Alarm Relays 0 7 1 - F113 2
2283 RRTD 2 - RTD #5 High Alarm Level 1 200 1 °C F1 130
2284 RRTD 2 - RTD #5 Alarm 0 2 1 - F115 0
2285 RRTD 2 - RTD #5 Alarm Relays 0 7 1 - F113 1
2286 RRTD 2 - RTD #5 Alarm Level 1 200 1 °C F1 130
2287 Record RRTD 2 - RTD #5 Alarms as Events 0 1 1 - F103 0
2288 RRTD 2 - RTD #5 Trip 0 2 1 - F115 0
2289 Enable RRTD 2 - RTD #5 Trip Voting 0 13 1 - F122 1
228A RRTD 2 - RTD #5 Trip Relays 0 7 1 - F111 1
228B RRTD 2 - RTD #5 Trip Level 1 200 1 °C F1 130
228C RRTD 2 - RTD #5 RTD Type 0 3 1 - F120 0
2290 First Character of RRTD 2 - RTD #5 Name 32 127 1 - F1 ’R’
↓↓
2293 8th Character of RRTD 2 - RTD #5 Name 32 127 1 - F1 " "
... Reserved
RRTD 2 – RTD #6
22A0 RRTD 2 - RTD #6 Application 0 4 1 - F121 0
22A1 RRTD 2 - RTD #6 High Alarm 0 2 1 - F115 0
22A2 RRTD 2 - RTD #6 High Alarm Relays 0 7 1 - F113 1
22A3 RRTD 2 - RTD #6 High Alarm Level 1 200 1 °C F1 130
22A4 RRTD 2 - RTD #6 Alarm 0 2 1 - F115 0
22A5 RRTD 2 - RTD #6 Alarm Relays 0 7 1 - F113 1
22A6 RRTD 2 - RTD #6 Alarm Level 1 200 1 °C F1 130
22A7 Record RRTD 2 - RTD #6 Alarms as Events 0 1 1 - F103 0
22A8 RRTD 2 - RTD #6 Trip 0 2 1 - F115 0
22A9 Enable RRTD 2 - RTD #6 Trip Voting 0 13 1 - F122 1
22AA RRTD 2 - RTD #6 Trip Relays 0 7 1 - F111 1
22AB RRTD 2 - RTD #6 Trip Level 1 200 1 °C F1 130
22AC RRTD 2 - RTD #6 RTD Type 0 3 1 - F120 0
22B0 First Character of RRTD 2 - RTD #6 Name 32 127 1 - F1 ’R’
↓↓
22B3 8th Character of RRTD 2 - RTD #6 Name 32 127 1 - F1 " "
... Reserved
RRTD 2 – RTD #7
22C0 RRTD 2 - RTD #7 Application 0 4 1 - F121 0
22C1 RRTD 2 - RTD #7 High Alarm 0 2 1 - F115 0
22C2 RRTD 2 - RTD #7 High Alarm Relays 0 7 1 - F113 2
22C3 RRTD 2 - RTD #7 High Alarm Level 1 200 1 °C F1 130
22C4 RRTD 2 - RTD #7 Alarm 0 2 1 - F115 0
22C5 RRTD 2 - RTD #7 Alarm Relays 0 7 1 - F113 1
22C6 RRTD 2 - RTD #7 Alarm Level 1 200 1 °C F1 130
22C7 Record RRTD 2 - RTD #7 Alarms as Events 0 1 1 - F103 0
22C8 RRTD 2 - RTD #7 Trip 0 2 1 - F115 0
22C9 Enable RRTD 2 - RTD #7 Trip Voting 0 13 1 - F122 1
22CA RRTD 2 - RTD #7 Trip Relays 0 7 1 - F111 1
22CB RRTD 2 - RTD #7 Trip Level 1 200 1 °C F1 130
22CC RRTD 2 - RTD #7 RTD Type 0 3 1 - F120 0
22D0 First Character of RRTD 2 - RTD #7 Name 32 127 1 - F1 ’R’
↓↓
22D3 8th Character of RRTD 2 - RTD #7 Name 32 127 1 - F1 ’ ’
... Reserved
RRTD 2 – RTD #8
22E0 RRTD 2 - RTD #8 Application 0 4 1 - F121 0
22E1 RRTD 2 - RTD #8 High Alarm 0 2 1 - F115 0
22E2 RRTD 2 - RTD #8 High Alarm Relays 0 7 1 - F113 2
22E3 RRTD 2 - RTD #8 High Alarm Level 1 200 1 °C F1 130
Table CG–10: MEMORY MAP (Sheet 35 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
