CG74 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
1DF8 Speed 2 Undercurrent Trip Level 10 99 1 0.01 × FLA F3 70
1DF9 Speed 2 Undercurrent Trip Delay 1 255 1 s F1 1
... Reserved
SPEED 2 ACCELERATION
1E00 Speed 2 Acceleration Timer from Start 10 2500 10 s F2 100
1E01
Speed 2 Acceleration Timer from Speed 1
to 2
20 2500 1 s F2 200
1E02 Speed 2 Speed Switch Time Delay 5 1000 5 100 ms F2 20
DATA LOGGER
1E20 Start/Stop Data Log 0 2 1 - F187
0 (=Select
Command)
1E21 Log Interval 0 3600 1 - F1 3600
1E22 Recording Type 0 1 1 - F188
0 (=Run To
Fill)
1E23 Data Log Memory Access Block Number 0 255 1 - F1 0, 1 (=null)
1E24 Channel 1 Log Assignment 0 102 1 - F189 0 (=None)
1E25 Channel 2 Log Assignment 0 102 1 - F189 0 (=None)
1E26 Channel 3 Log Assignment 0 102 1 - F189 0 (=None)
1E27 Channel 4 Log Assignment 0 102 1 - F189 0 (=None)
1E28 Channel 5 Log Assignment 0 102 1 - F189 0 (=None)
1E29 Channel 6 Log Assignment 0 102 1 - F189 0 (=None)
1E2A Channel 7 Log Assignment 0 102 1 - F189 0 (=None)
1E2B Channel 8 Log Assignment 0 102 1 - F189 0 (=None)
1E2C Channel 9 Log Assignment 0 102 1 - F189 0 (=None)
1E2D Channel 10 Log Assignment 0 102 1 - F189 0 (=None)
1E2E Channel 11 Log Assignment 0 102 1 - F189 0 (=None)
1E2F Channel 12 Log Assignment 0 102 1 - F189 0 (=None)
1E30 Channel 13 Log Assignment 0 102 1 - F189 0 (=None)
1E31 Channel 14 Log Assignment 0 102 1 - F189 0 (=None)
1E32 Channel 15 Log Assignment 0 102 1 - F189 0 (=None)
1E33 Channel 16 Log Assignment 0 102 1 - F189 0 (=None)
... Reserved
TEST OUTPUT RELAYS
1F80 Force Trip Relay 0 2 1 - F150 0
1F81 Force Trip Relay Duration 1 300 1 s F1 0
1F82 Force AUX1 Relay 0 2 1 - F150 0
1F83 Force AUX1 Relay Duration 1 300 1 s F1 0
1F84 Force AUX2 Relay 0 2 1 - F150 0
1F85 Force AUX2 Relay Duration 1 300 1 s F1 0
1F86 Force Alarm Relay 0 2 1 - F150 0
1F87 Force Alarm Relay Range 1 300 1 s F1 0
... Reserved
TEST ANALOG OUTPUTS
1F90 Force Analog Outputs 0 1 1 - F126 0
1F91 Analog Output 1 Forced Value 0 100 1 % range F1 0
1F92 Analog Output 2 Forced Value 0 100 1 % range F1 0
1F93 Analog Output 3 Forced Value 0 100 1 % range F1 0
1F94 Analog Output 4 Forced Value 0 100 1 % range F1 0
... Reserved
REMOTE RTD SLAVE ADDRESSES
1FF0 RRTD1 - Slave Address 0 254 1 - F1 0
1FF1 RRTD2 - Slave Address 0 254 1 - F1 0
1FF2 RRTD3 - Slave Address 0 254 1 - F1 0
1FF3 RRTD4 - Slave Address 0 254 1 - F1 0
... Reserved
RRTD 1 – RTD #1
2000 RRTD 1 - RTD #1 Application 0 4 1 - F121 0
2001 RRTD 1 - RTD #1 High Alarm 0 2 1 - F115 0
2002 RRTD 1 - RTD #1 High Alarm Relays 0 7 1 - F113 2
2003 RRTD 1 - RTD #1 High Alarm Level 1 200 1 °C F1 130
Table CG–10: MEMORY MAP (Sheet 29 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT

GE 369 Specifications

General

Current Rating	5A
Frequency	50/60 Hz
Mounting	Panel Mount
Protection Functions	Overcurrent, Undervoltage
Type	Digital protective relay
Operating Temperature	-20°C to 60°C
