CG108 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
F119
Unsigned 16 bit integer BACKUP RELAYS
0None
1Aux 1
2Aux1 & Aux2
3Aux2
F120
Unsigned 16 bit integer RTD TYPE
0 100 Ohm Platinum
1 120 Ohm Nickel
2 100 Ohm Nickel
310 Ohm Copper
F121
Unsigned 16 bit integer RTD APPLICATION
0None
1Stator
2Bearing
3Ambient
4Other
F122
Unsigned 16 bit integer LOCAL/REMOTE RTD VOTING SELECTION
0Off
1RTD #1
2RTD #2
3RTD #3
4RTD #4
5RTD #5
6RTD #6
7RTD #7
8RTD #8
9RTD #9
10 RTD #10
11 RTD #11
12 RTD #12
13 All Stator
Table CG–11: Memory Map Data Formats (Sheet 6 of 27)
