CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG127
F169
Unsigned 16 Bit Integer TRIP AND ALARM RELAYS
0None
1Trip
2Alarm
3Aux1
4Aux2
5 Trip and Alarm
6 Trip and Aux1
7 Trip and Aux2
8 Alarm and Aux1
9 Alarm and Aux2
10 Aux1 and Aux2
11 Trip and Alarm and Aux1
12 Trip and Alarm and Aux2
13 Trip and Aux1 and Aux2
14 Alarm and Aux1 and Aux2
15 All Relays
F180
Unsigned 16 Bit Integer ANSI/IEEE DEVICE
0 37 - Undercurrent/Underpower
146 - Current Unbalance
2 48 - Incomplete Sequence
349 - Thermal Model
4 50 - Short Circuit and Backup
551 - Overload Alarm
6 51G - Ground Fault
7 66 - Starts Per Hour / Time Between Starts
F181
Unsigned 16 Bit Integer OUTPUT RELAY TYPE
0Latched
1Pulsed
F182
Unsigned 16 Bit Integer PROTECTION FUNCTION BLOCKING STATUS
0 Not Blocked
1Blocked
Table CG–11: Memory Map Data Formats (Sheet 25 of 27)
CODE TYPE DEFINITION
