CG98 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
RRTD 4 – DIGITAL INPUT 4
2AE0
1st & 2nd Character of Digital Input 4
Name
32 127 1 - F22 ’GE’
↓↓
2AE5
11th & 12th Character of Digital Input 4
Name
32 127 1 - F22 ’GE’
2AF0 Digital Input 4 Type 0 1 1 - F116 0
2AF1 Reserved
2AF2 Digital Input 4 Alarm 0 2 1 - F115 0
2AF3 Digital Input 4 Alarm Relays 0 6 1 - F113 0
2AF4 Digital Input 4 Alarm Delay 1 50000 1 100ms F2 50
2AF5 Digital Input 4 Alarm Events 0 1 1 - F103 0
2AF6 Digital Input 4 Trip 0 2 1 - F115 0
2AF7 Digital Input 4 Trip Relays 0 6 1 - F111 0
2AF8 Digital Input 4 Trip Delay 1 50000 1 100ms F2 50
2AF9 Digital Input 4 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 4 – DIGITAL INPUT 1
2B00
1st & 2nd Character of Digital Input 1
Name
32 127 1 - F22 ’GE’
↓↓
2B05
11th & 12th Character of Digital Input 1
Name
32 127 1 - F22 ’GE’
2B10 Digital Input 1 Type 0 1 1 - F116 0
2B11 Reserved
2B12 Digital Input 1 Alarm 0 2 1 - F115 0
2B13 Digital Input 1 Alarm Relays 0 6 1 - F113 0
2B14 Digital Input 1 Alarm Delay 1 50000 1 100ms F2 50
2B15 Digital Input 1 Alarm Events 0 1 1 - F103 0
2B16 Digital Input 1 Trip 0 2 1 - F115 0
2B17 Digital Input 1 Trip Relays 0 6 1 - F111 0
2B18 Digital Input 1 Trip Delay 1 50000 1 100ms F2 50
2B19 Digital Input 1 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 4 – DIGITAL INPUT 6
2B20
1st & 2nd Character of Digital Input 6
Name
32 127 1 - F22 ’GE’
↓↓
2B25
11th & 12th Character of Digital Input 6
Name
32 127 1 - F22 ’GE’
2B30 Digital Input 6 Type 0 1 1 - F116 0
2B31 Reserved
2B32 Digital Input 6 Alarm 0 2 1 - F115 0
2B33 Digital Input 6 Alarm Relays 0 6 1 - F113 0
2B34 Digital Input 6 Alarm Delay 1 50000 1 100ms F2 50
2B35 Digital Input 6 Alarm Events 0 1 1 - F103 0
2B36 Digital Input 6 Trip 0 2 1 - F115 0
2B37 Digital Input 6 Trip Relays 0 6 1 - F111 0
2B38 Digital Input 6 Trip Delay 1 50000 1 100ms F2 50
2B39 Digital Input 6 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 4 – DIGITAL INPUT 3
2B40
1st & 2nd Character of Digital Input 3
Name
32 127 1 - F22 ’GE’
↓↓
2B45
11th & 12th Character of Digital Input 3
Name
32 127 1 - F22 ’GE’
2B50 Digital Input 3 Type 0 1 1 - F116 0
2B51 Reserved
2B52 Digital Input 3 Alarm 0 2 1 - F115 0
2B53 Digital Input 3 Alarm Relays 0 6 1 - F113 0
2B54 Digital Input 3 Alarm Delay 1 50000 1 100ms F2 50
Table CG–10: MEMORY MAP (Sheet 53 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
