CG58 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
0872 Digital Input 6 0 1 1 - F131 0
0873 Digital Input 5 0 1 1 - F131 0
0874 Digital Input 2 0 1 1 - F131 0
0875 Digital Input 1 0 1 1 - F131 0
... Reserved
RRTD 1 OUTPUT RELAY STATUS
0880 RRTD 1 - Trip 0 2 1 N/A F150 2
0881 RRTD 1 - Alarm 0 2 1 N/A F150 2
0882 RRTD 1 - Aux. 1 0 2 1 N/A F150 2
0883 RRTD 1 - Aux. 2 0 2 1 N/A F150 2
RRTD 1 DIGITAL INPUT AND OUTPUT RELAY STATUS
0884 RRTD1 Digital Input & Output Relay Status N/A N/A N/A N/A F193 0
... Reserved
RRTD 2 OUTPUT RELAY STATUS
0890 RRTD 2 - Trip 0 2 1 N/A F150 2
0891 RRTD 2 - Alarm 0 2 1 N/A F150 2
0892 RRTD 2 - Aux. 1 0 2 1 N/A F150 2
0893 RRTD 2 - Aux. 2 0 2 1 N/A F150 2
RRTD 2 DIGITAL INPUT AND OUTPUT RELAY STATUS
0894 RRTD2 Digital Input & Output Relay Status N/A N/A N/A N/A F193 0
... Reserved
RRTD 3 OUTPUT RELAY STATUS
08A0 RRTD 3 - Trip 0 2 1 N/A F150 2
08A1 RRTD 3 - Alarm 0 2 1 N/A F150 2
08A2 RRTD 3 - Aux. 1 0 2 1 N/A F150 2
08A3 RRTD 3 - Aux. 2 0 2 1 N/A F150 2
RRTD 3 DIGITAL INPUT AND OUTPUT RELAY STATUS
08A4 RRTD3 Digital Input & Output Relay Status N/A N/A N/A N/A F193 0
... Reserved
RRTD 4 OUTPUT RELAY STATUS
08B0 RRTD 4 - Trip 0 2 1 N/A F150 2
08B1 RRTD 4 - Alarm 0 2 1 N/A F150 2
08B2 RRTD 4 - Aux. 1 0 2 1 N/A F150 2
08B3 RRTD 4 - Aux. 2 0 2 1 N/A F150 2
RRTD 4 DIGITAL INPUT AND OUTPUT RELAY STATUS
08B4 RRTD4 Digital Input & Output Relay Status N/A N/A N/A N/A F193 0
... Reserved
COMMUNICATIONS MODULE
08C0 Ethernet Module Status 0 65535 1 N/A F164 -
08C1 Anybus Module Software Revision - - - - F16 -
... Reserved
PROTECTION FUNCTION BLOCKING
08D0 Protection Functions Currently Blocked 0 256 1 N/A F180 0
... Reserved
SETPOINTS (ADDRESSES 1000 TO 1FFF)
DISPLAY PREFERENCES
1000 Default Message Cycle Time 5 100 1 s F1 20
1001 Default Message Timeout 10 900 1 s F1 300
1002 Reserved
1003 Flash Message 1 10 1 s F1 2
1004 Temperature Display Units 0 1 1 - F100 0
1005 Energy Unit Display 0 1 1 - F166 0
... Reserved
EVENT RECORDS
1006 Motor Running Events 0 1 1 - F103 0
1007 Motor Stopped Events 0 1 1 - F103 0
WAVEFORM CAPTURE
1008 Trigger Position 0 100 1 % F1 20
... Reserved
Table CG–10: MEMORY MAP (Sheet 13 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
