CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG53
RRTD 2 TEMPERATURES
0610 RRTD 2 - RTD - Hottest Stator Number 0 12 1 - F1 0
0611
RRTD 2 - RTD - Hottest Stator
Temperature
-40 200 1 °C F4 40
0612 RRTD 2 - RTD #1Temperature -40 200 1 °C F4 40
0613 RRTD 2 - RTD #2 Temperature -40 200 1 °C F4 40
0614 RRTD 2 - RTD #3 Temperature -40 200 1 °C F4 40
0615 RRTD 2 - RTD #4 Temperature -40 200 1 °C F4 40
0616 RRTD 2 - RTD #5 Temperature -40 200 1 °C F4 40
0617 RRTD 2 - RTD #6 Temperature -40 200 1 °C F4 40
0618 RRTD 2 - RTD #7 Temperature -40 200 1 °C F4 40
0619 RRTD 2 - RTD #8 Temperature -40 200 1 °C F4 40
061A RRTD 2 - RTD #9 Temperature -40 200 1 °C F4 40
061B RRTD 2 - RTD #10 Temperature -40 200 1 °C F4 40
061C RRTD 2 - RTD #11 Temperature -40 200 1 °C F4 40
061D RRTD 2 - RTD #12 Temperature -40 200 1 °C F4 40
... Reserved
RRTD 3 TEMPERATURES
0620 RRTD 3 - RTD - Hottest Stator Number 0 12 1 - F1 0
0621
RRTD 3 - RTD - Hottest Stator
Temperature
-40 200 1 °C F4 40
0622 RRTD 3 - RTD #1 Temperature -40 200 1 °C F4 40
0623 RRTD 3 - RTD #2 Temperature -40 200 1 °C F4 40
0624 RRTD 3 - RTD #3 Temperature -40 200 1 °C F4 40
0625 RRTD 3 - RTD #4 Temperature -40 200 1 °C F4 40
0626 RRTD 3 - RTD #5 Temperature -40 200 1 °C F4 40
0627 RRTD 3 - RTD #6 Temperature -40 200 1 °C F4 40
0628 RRTD 3 - RTD #7 Temperature -40 200 1 °C F4 40
0629 RRTD 3 - RTD #8 Temperature -40 200 1 °C F4 40
062A RRTD 3 - RTD #9 Temperature -40 200 1 °C F4 40
062B RRTD 3 - RTD #10 Temperature -40 200 1 °C F4 40
062C RRTD 3 - RTD #11 Temperature -40 200 1 °C F4 40
062D RRTD 3 - RTD #12 Temperature -40 200 1 °C F4 40
... Reserved
RRTD 4 TEMPERATURES
0630 RRTD 4 - RTD- Hottest Stator Number 0 12 1 - F1 0
0631 RRTD 4 - RTD- Hottest Stator Temperature -40 200 1 °C F4 40
0632 RRTD 4 - RTD#1 Temperature -40 200 1 °C F4 40
0633 RRTD 4 - RTD#2 Temperature -40 200 1 °C F4 40
0634 RRTD 4 - RTD#3 Temperature -40 200 1 °C F4 40
0635 RRTD 4 - RTD#4 Temperature -40 200 1 °C F4 40
0636 RRTD 4 - RTD#5 Temperature -40 200 1 °C F4 40
0637 RRTD 4 - RTD#6 Temperature -40 200 1 °C F4 40
0638 RRTD 4 - RTD#7 Temperature -40 200 1 °C F4 40
0639 RRTD 4 - RTD#8 Temperature -40 200 1 °C F4 40
063A RRTD 4 - RTD#9 Temperature -40 200 1 °C F4 40
063B RRTD 4 - RTD#10 Temperature -40 200 1 °C F4 40
063C RRTD 4 - RTD#11 Temperature -40 200 1 °C F4 40
063D RRTD 4 - RTD#12 Temperature -40 200 1 °C F4 40
LOSS OF RRTD COMMUNICATIONS
063E Lost RRTD Communications alarm 0 4 1 - F123 0
063F Actively Communicating RRTDs 0 15 - - F183 -
RRTD 1 ALARM STATUS
0650 RRTD 1 - RTD #1 Alarm Status 0 4 1 - F123 0
0651 RRTD 1 - RTD #2 Alarm Status 0 4 1 - F123 0
0652 RRTD 1 - RTD #3 Alarm Status 0 4 1 - F123 0
0653 RRTD 1 - RTD #4 Alarm Status 0 4 1 - F123 0
0654 RRTD 1 - RTD #5 Alarm Status 0 4 1 - F123 0
0655 RRTD 1 - RTD #6 Alarm Status 0 4 1 - F123 0
0656 RRTD 1 - RTD #7 Alarm Status 0 4 1 - F123 0
Table CG–10: MEMORY MAP (Sheet 8 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
