CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG59
369 COMMUNICATIONS
100F Reset Profibus Interface 0 1 1 - F103 0
1010 Slave Address 1 254 1 - F1 254
1011 Computer RS232 Baud Rate 0 4 1 - F101 4
1012 Computer RS232 Parity 0 2 1 - F102 0
1013 Channel 1 Parity 0 2 1 - F102 0
1014 Channel 1 Baud Rate 0 4 1 - F101 4
1015 Channel 2 Parity 0 2 1 - F102 0
1016 Channel 2 Baud Rate 0 4 1 - F101 4
1017 Channel 3 Parity 0 2 1 - F102 0
1018 Channel 3 Baud Rate 0 4 1 - F101 4
1019 Channel 3 Connection 0 1 1 - F151 0
101A Channel 3 Application 0 1 1 - F149 0
101B Profibus Slave Address 1 126 1 - F1 125
101C IP Address Octet 1 0 255 1 - F1 127
101D IP Address Octet 2 0 255 1 - F1 0
101E IP Address Octet 3 0 255 1 - F1 0
101F IP Address Octet 4 0 255 1 - F1 1
1020 Subnet Mask Octet 1 0 255 1 - F1 255
1021 Subnet Mask Octet 2 0 255 1 - F1 255
1022 Subnet Mask Octet 3 0 255 1 - F1 255
1023 Subnet Mask Octet 4 0 255 1 - F1 0
1024 Gateway Address Octet 1 0 255 1 - F1 127
1025 Gateway Address Octet 2 0 255 1 - F1 0
1026 Gateway Address Octet 3 0 255 1 - F1 0
1027 Gateway Address Octet 4 0 255 1 - F1 1
1028 DeviceNet MAC ID 0 63 1 - F1 63
1029 DeviceNet Baud Rate 0 2 1 - F170 0
... Reserved
REAL TIME CLOCK
1030 Date (2 words) valid date N/A - F18 -
1034 Time (2 words) valid time N/A - F19 -
... Reserved
DEFAULT MESSAGES
1041 Default to Current Metering 0 1 1 - F103 0
1042 Default to Motor Load 0 1 1 - F103 0
1043 Default to Delta Voltage Metering 0 1 1 - F103 0
1044 Default to Power Factor 0 1 1 - F103 0
1045 Default to Positive Watthours 0 1 1 - F103 0
1046 Default to Real Power 0 1 1 - F103 0
1047 Default to Reactive Power 0 1 1 - F103 0
1048 Default to Hottest Stator RTD 0 1 1 - F103 0
1049 Default to Text Message 1 0 1 1 - F103 0
104A Default to Text Message 2 0 1 1 - F103 0
104B Default to Text Message 3 0 1 1 - F103 0
104C Default to Text Message 4 0 1 1 - F103 0
104D Default to Text Message 5 0 1 1 - F103 0
104E
Default to Hottest Stator RTD
Temperature
0 1 1 - F103 0
104F Default to Unbalace Biased Motor Load 0 1 1 - F103 0
... Reserved - - - - - -
MESSAGE SCRATCHPAD
1060
1st & 2nd Character of 1st Scratchpad
Message
32 127 1 - F1 ’T’
↓↓
1073
39th & 40th Character of 1st Scratchpad
Message
32 127 1 - F1 " "
1074
1st & 2nd Character of 2nd Scratchpad
Message
32 127 1 - F1 ’T’
↓↓
Table CG–10: MEMORY MAP (Sheet 14 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
