CG126 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
F163
Unsigned 16 Bit Integer RRTD DIGITAL INPUT FUNCTION
0Off
1 undefined
2 General Switch
3 Digital Counter
F164
Unsigned 16 Bit Integer COMMUNICATIONS MODULE STATUS
0x0001 Ethernet Connection OK
0x0002 IP Configuration OK
0x0004 IP Address Error
0x0008 Communications Module Error
0x0010 Network Activity Present
F165
Unsigned 16 Bit Integer OVERALL HOTTEST STATOR RTD OWNER
0 No RTDs programmed or available
1 Remote RTD #1
2 Remote RTD #2
3 Remote RTD #3
4 Remote RTD #4
5Local 369
F166
Unsigned 16 Bit Integer ENERGY UNIT DISPLAY
0Mega
1Kilo
Table CG–11: Memory Map Data Formats (Sheet 24 of 27)
