CG128 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
F183
16 bits ACTIVELY COMMUNICATING RRTDs
xxxx xxxx xxxx 0000 No RRTDs Actively Communicating
xxxx xxxx xxxx xxx1 RRTD1 Communicating
xxxx xxxx xxxx xx1x RRTD2 Communicating
xxxx xxxx xxxx x1xx RRTD3 Communicating
xxxx xxxx xxxx 1xxx RRTD4 Communicating
F184
Unsigned 16 bit Integer DATA RECORD ACCESS TYPE
0 Access Trace Memory data
1 Access Motor Start Data Logger data
F185
Unsigned 16 bit Integer VT CONNECTION TYPE
0 Phase-Neutral Voltage
1 Phase-Phase Voltage
F186
Unsigned 16 bit Integer MOTOR SPEED
0 Not Programmed
1 Speed 1 (Low Speed)
2 Speed 2 (High Speed)
F187
16 bitS START/STOP DATA LOG COMMAND
0 None (Select Command)
1Start Log
2Stop Log
F188
16 bitS DATA LOG RECORDING TYPE
0 Run To Fill
1Circulate
F189 SEE TABLE 9-12 BELOW
F190
16 bitS DATA LOG STATUS
0 Stopped
1 Running
F191 16 bits DATA LOG START/STOP METHOD
xxxx xxxx xxxx xxx1 Log 1/9/17/25/33/41/49 Start Method
xxxx xxxx xxxx xx1x Log 1/9/17/25/33/41/49 Stop Method
xxxx xxxx xxxx x1xx Log 2/10/18/25/34/42/50 Start Method
xxxx xxxx xxxx 1xxx Log 2/10/18/25/34/42/50 Stop Method
xxxx xxxx xxx1 xxxx Log 3/11/19/25/35/43/ Start Method
xxxx xxxx xx1x xxxx Log 3/11/19/25/35/43/ Stop Method
xxxx xxxx x1xx xxxx Log 4/12/20/25/36/44/ Start Method
xxxx xxxx 1xxx xxxx Log 4/12/20/25/36/44/ Stop Method
Table CG–11: Memory Map Data Formats (Sheet 26 of 27)
CODE TYPE DEFINITION
