CG60 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
1087
39th & 40th Character of 2nd Scratchpad
Message
32 127 1 - F1 " "
1088
1st & 2nd Character of 3rd Scratchpad
Message
32 127 1 - F1 ’T’
↓↓
109B
39th & 40th Character of 3rd Scratchpad
Message
32 127 1 - F1 " "
109C
1st & 2nd Character of 4th Scratchpad
Message
32 127 1 - F1 ’T’
↓↓
10AF
39th & 40th Character of 4th Scratchpad
Message
32 127 1 - F1 " "
10B0
1st & 2nd Character of 5th Scratchpad
Message
32 127 1 - F1 ’T’
↓↓
10C3
39th & 40th Character of 5th Scratchpad
Message
32 127 1 - F1 " "
... Reserved
CLEAR PRESET DATA
1130 Clear Last Trip Data 0 1 1 - F103 0
1131 Clear Peak Demand Data 0 1 1 - F103 0
1132 Clear RTD Maximums 0 1 1 - F103 0
1133 Preset Positive MWh 0 65535 1 MWh F1 0
1134 Clear Trip Counters 0 1 1 - F103 0
1135 Preset Digital Counter 0 65535 1 - F1 0
1136 Clear Event Records 0 1 1 - F103 0
1137 Preset Positive Mvarh 0 65535 1 Mvarh F1 0
1138 Preset Negative Mvarh 0 65535 1 Mvarh F1 0
1139 Preset Number Of Motor Starts 0 50000 1 - F1 0
113A Preset Number Of Emergency Restarts 0 50000 1 - F1 0
113B Preset Motor Running Hours 0 65535 1 - F1 0
113C Preset Autorestart Start Attempts 0 50000 1 - F1 0
... Reserved
1140 Clear Motor Data 0 1 1 - F103 0
1141 Reserved - - - - - -
1142 Clear All Data 0 1 1 - F103 0
1143 RRTD 1 - Preset Digital Counter 0 65535 1 - F1 0
1144 RRTD 2 - Preset Digital Counter 0 65535 1 - F1 0
1145 RRTD 3 - Preset Digital Counter 0 65535 1 - F1 0
1146 RRTD 4 - Preset Digital Counter 0 65535 1 - F1 0
1147 Clear Energy Data 0 1 1 - F103 0
... Reserved
CT/VT SETUP
1180 Phase CT Primary 1 5000 1 A F1 500
1181 Motor Full Load Amps 1 5000 1 A F1 10
1182 Ground CT Type 0 3 1 - F104 2
1183 Ground CT Primary 1 5000 1 A F1 100
... Reserved
1190 Enable Two Speed Motor Protection 0 1 1 N/A F103 0
1191 Speed 2 Phase CT Primary 1 5000 1 A F1 5000
1192 Speed 2 Motor Full Load Amps 1 5000 1 A F1 10
... Reserved
11A0 Voltage Transformer Connection Type 0 2 1 - F106 0
11A1 Voltage Transformer Ratio 100 24000 1 - F3 35
11A2 Motor Rated Voltage 100 20000 1 V F1 4160
... Reserved
11C0 Nominal Frequency 0 2 1 - F107 0
11C1 System Phase Sequence 0 1 1 - F124 0
11C2 Speed 2 System Phase Sequence 0 1 1 - F124 0
... Reserved
SERIAL COMM CONTROL
11C8 Serial Communication Control 0 1 1 - F103 0
Table CG–10: MEMORY MAP (Sheet 15 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
