GE 369 User Manual

CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG91
RRTD 1 – ANALOG OUTPUTS
27E0 Enable Analog Output 1 0 1 1 - F103 0
27E1 Assign Analog Output 1 Output Range 0 2 1 - F26 0
27E2 Assign Analog Output 1 Parameter 12 24 1 - F127 13
27E3 Analog Output 1 Minimum -40 200 1 - F4 -40
27E4 Analog Output 1 Maximum -40 200 1 - F4 200
27E5 Enable Analog Output 2 0 1 1 - F103 0
27E6 Assign Analog Output 2 Output Range 0 2 1 - F26 0
27E7 Assign Analog Output 2 Parameter 12 24 1 - F127 13
27E8 Analog Output 2 Minimum -40 200 1 - F4 -40
27E9 Analog Output 2 Maximum -40 200 1 - F4 200
27EA Enable Analog Output 3 0 1 1 - F103 0
27EB Assign Analog Output 3 Output Range 0 2 1 - F26 0
27EC Assign Analog Output 3 Parameter 12 24 1 - F127 13
27ED Analog Output 3 Minimum -40 200 1 - F4 -40
27EE Analog Output 3 Maximum -40 200 1 - F4 200
27EF Enable Analog Output 4 0 1 1 - F103 0
27F0 Assign Analog Output 4 Output Range 0 2 1 - F26 0
27F1 Assign Analog Output 4 Parameter 12 24 1 - F127 13
27F2 Analog Output 4 Minimum -40 200 1 - F4 -40
27F3 Analog Output 4 Maximum -40 200 1 - F4 200
... Reserved
RRTD 2 – ANALOG OUTPUTS
2800 Enable Analog Output 1 0 1 1 - F103 0
2801 Assign Analog Output 1 Output Range 0 2 1 - F26 0
2802 Assign Analog Output 1 Parameter 12 24 1 - F127 13
2803 Analog Output 1 Minimum -40 200 1 - F4 -40
2804 Analog Output 1 Maximum -40 200 1 - F4 200
2805 Enable Analog Output 2 0 1 1 - F103 0
2806 Assign Analog Output 2 Output Range 0 2 1 - F26 0
2807 Assign Analog Output 2 Parameter 12 24 1 - F127 13
2808 Analog Output 2 Minimum -40 200 1 - F4 -40
2809 Analog Output 2 Maximum -40 200 1 - F4 200
280A Enable Analog Output 3 0 1 1 - F103 0
280B Assign Analog Output 3 Output Range 0 2 1 - F26 0
280C Assign Analog Output 3 Parameter 12 24 1 - F127 13
280D Analog Output 3 Minimum -40 200 1 - F4 -40
280E Analog Output 3 Maximum -40 200 1 - F4 200
280F Enable Analog Output 4 0 1 1 - F103 0
2810 Assign Analog Output 4 Output Range 0 2 1 - F26 0
2811 Assign Analog Output 4 Parameter 12 24 1 - F127 13
2812 Analog Output 4 Minimum -40 200 1 - F4 -40
2813 Analog Output 4 Maximum -40 200 1 - F4 200
... Reserved
RRTD 3 – ANALOG OUTPUTS
2820 Enable Analog Output 1 0 1 1 - F103 0
2821 Assign Analog Output 1 Output Range 0 2 1 - F26 0
2822 Assign Analog Output 1 Parameter 12 24 1 - F127 13
2823 Analog Output 1 Minimum -40 200 1 - F4 -40
2824 Analog Output 1 Maximum -40 200 1 - F4 200
2825 Enable Analog Output 2 0 1 1 - F103 0
2826 Assign Analog Output 2 Output Range 0 2 1 - F26 0
2827 Assign Analog Output 2 Parameter 12 24 1 - F127 13
2828 Analog Output 2 Minimum -40 200 1 - F4 -40
2829 Analog Output 2 Maximum -40 200 1 - F4 200
282A Enable Analog Output 3 0 1 1 - F103 0
282B Assign Analog Output 3 Output Range 0 2 1 - F26 0
282C Assign Analog Output 3 Parameter 12 24 1 - F127 13
282D Analog Output 3 Minimum -40 200 1 - F4 -40
Table CG–10: MEMORY MAP (Sheet 46 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT

GE 369 Specifications

General

Current Rating	5A
Frequency	50/60 Hz
Mounting	Panel Mount
Protection Functions	Overcurrent, Undervoltage
Type	Digital protective relay
Operating Temperature	-20°C to 60°C
