CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG101
3003
Event Record Selector (1=oldest,
512=newest)
1 512 1 N/A F1 1
3004 Cause of Event 0 281 1 - F134 0
3005 Time of Event (2 words) N/A N/A N/A N/A F19 N/A
3007 Date of Event (2 words) N/A N/A N/A N/A F18 N/A
3009 Motor Speed During Event 0 2 1 N/A F186 N/A
... Reserved
300B Event Phase A Current 0 65535 1 A F1 0
300C Event Phase B Current 0 65535 1 A F1 0
300D Event Phase C Current 0 65535 1 A F1 0
300E Event Motor Load 0 2000 1 FLA F3 0
300F Event Current Unbalance 0 100 1 % F1 0
3010 Event Ground Current 0 50000 1 A F23 0
3011 Event Hottest Stator RTD Owner 0 5 1 N/A F165 0
3012 Event Hottest Stator RTD 0 12 1 - F1 0
3013 Event Temperature of Hottest Stator RTD -40 200 1 o C F4 0
... Reserved
301A Event Voltage Vab 0 20000 1 V F1 0
301B Event Voltage Vbc 0 20000 1 V F1 0
301C Event Voltage Vca 0 20000 1 V F1 0
301D Event Voltage Van 0 20000 1 V F1 0
301E Event Voltage Vbn 0 20000 1 V F1 0
301F Event Voltage Vcn 0 20000 1 V F1 0
3020 Event System Frequency 0 12000 1 Hz F3 0
3021 Event Real Power -32000 32000 1 kW F4 0
3022 Event Reactive Power -32000 32000 1 kvar F4 0
3023 Event Apparent Power 0 50000 1 kVA F1 0
3024 Event Power Factor -99 100 1 - F21 0
... Reserved
WAVEFORM CAPTURE / MOTOR START DATA LOGGER
30EF Buffer Memory Access Type 0 2 1 - F184
0 (Trace
Memory)
30F0 Trace Memory Clear Date N/A N/A N/A N/A F18 N/A
30F2 Trace Memory Clear Time N/A N/A N/A N/A F19 N/A
30F4 Trace Memory Triggers Since Last Clear 0 65535 1 - F1 0
30F5
Trace Memory Buffer Selector 0 3 1 - F1 0
Motor Start Log Buffer Selector 0 6 1 - F1
0 (None
Selected)
30F6
Trace Memory Channel Selector 0 6 1 - F1 0
Motor Start Log Channel Selector 0 11 1 - F1
0 (None
Selected)
30F7
Trace Memory Trigger Date N/A N/A N/A N/A F18 N/A
Motor Start Log Trigger Date N/A N/A N/A N/A F18 N/A
30F9
Trace Memory Trigger Time N/A N/A N/A N/A F19 N/A
Motor Start Log Trigger Time N/A N/A N/A N/A F19 N/A
30FB
1
Trace Memory Trigger Cause 0 2 1 - F85 N/A
Number of Recorded Motor Start Logs 0 6 1 - F1 0
30FC
1
Trace Memory Trigger Index 0 100 1 % F1 N/A
Motor Start Log Phase Voltage Type 0 1 1 - F185 N/A
... Reserved
3100
First Trace Memory Sample -32767 32767 1 - F4 N/A
First Memory Sample -32767 32767 1 - F4 N/A
↓↓
31FF
Last Trace Memory Sample -32767 32767 1 - F4 N/A
Last Memory Sample -32767 32767 1 - F4 N/A
DATA LOGGER LOG HEADER
3200 Log Time Interval 1 3600 1 s F1 3600
3201 Log Record Size 0 16 - Words F1 N/A
3202 Log Total Possible Records 0 16256 1 - F1 N/A
3203 Total Logs Since Last Clear 0 65535 1 - F1 0
3204 Total Logs Presently Used 0 50 1 - F1 0
Table CG–10: MEMORY MAP (Sheet 56 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
