GE 369 User Manual

CG88 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
RRTD 4 – RTD #6
26A0 RRTD 4 - RTD #6 Application 0 4 1 - F121 0
26A1 RRTD 4 - RTD #6 High Alarm 0 2 1 - F115 0
26A2 RRTD 4 - RTD #6 High Alarm Relays 0 7 1 - F113 1
26A3 RRTD 4 - RTD #6 High Alarm Level 1 200 1 °C F1 130
26A4 RRTD 4 - RTD #6 Alarm 0 2 1 - F115 0
26A5 RRTD 4 - RTD #6 Alarm Relays 0 7 1 - F113 1
26A6 RRTD 4 - RTD #6 Alarm Level 1 200 1 °C F1 130
26A7 Record RRTD 4 - RTD #6 Alarms as Events 0 1 1 - F103 0
26A8 RRTD 4 - RTD #6 Trip 0 2 1 - F115 0
26A9 Enable RRTD 4 - RTD #6 Trip Voting 0 13 1 - F122 1
26AA RRTD 4 - RTD #6 Trip Relays 0 7 1 - F111 1
26AB RRTD 4 - RTD #6 Trip Level 1 200 1 °C F1 130
26AC RRTD 4 - RTD #6 RTD Type 0 3 1 - F120 0
26B0 First Character of RRTD 4 - RTD #6 Name 32 127 1 - F1 ’R’
↓↓
26B3 8th Character of RRTD 4 - RTD #6 Name 32 127 1 - F1 " "
... Reserved
RRTD 4 – RTD #7
26C0 RRTD 4 - RTD #7 Application 0 4 1 - F121 0
26C1 RRTD 4 - RTD #7 High Alarm 0 2 1 - F115 0
26C2 RRTD 4 - RTD #7 High Alarm Relays 0 7 1 - F113 2
26C3 RRTD 4 - RTD #7 High Alarm Level 1 200 1 °C F1 130
26C4 RRTD 4 - RTD #7 Alarm 0 2 1 - F115 0
26C5 RRTD 4 - RTD #7 Alarm Relays 0 7 1 - F113 1
26C6 RRTD 4 - RTD #7 Alarm Level 1 200 1 °C F1 130
26C7 Record RRTD 4 - RTD #7 Alarms as Events 0 1 1 - F103 0
26C8 RRTD 4 - RTD #7 Trip 0 2 1 - F115 0
26C9 Enable RRTD 4 - RTD #7 Trip Voting 0 13 1 - F122 1
26CA RRTD 4 - RTD #7 Trip Relays 0 7 1 - F111 1
26CB RRTD 4 - RTD #7 Trip Level 1 200 1 °C F1 130
26CC RRTD 4 - RTD #7 RTD Type 0 3 1 - F120 0
26D0 First Character of RRTD 4 - RTD #7 Name 32 127 1 - F1 ’R’
↓↓
26D3 8th Character of RRTD 4 - RTD #7 Name 32 127 1 - F1 " "
... Reserved
RRTD 4 – RTD #8
26E0 RRTD 4 - RTD #8 Application 0 4 1 - F121 0
26E1 RRTD 4 - RTD #8 High Alarm 0 2 1 - F115 0
26E2 RRTD 4 - RTD #8 High Alarm Relays 0 7 1 - F113 2
26E3 RRTD 4 - RTD #8 High Alarm Level 1 200 1 °C F1 130
26E4 RRTD 4 - RTD #8 Alarm 0 2 1 - F115 0
26E5 RRTD 4 - RTD #8 Alarm Relays 0 7 1 - F113 1
26E6 RRTD 4 - RTD #8 Alarm Level 1 200 1 °C F1 130
26E7 Record RRTD 4 - RTD #8 Alarms as Events 0 1 1 - F103 0
26E8 RRTD 4 - RTD #8 Trip 0 2 1 - F115 0
26E9 Enable RRTD 4 - RTD #8 Trip Voting 0 13 1 - F122 1
26EA RRTD 4 - RTD #8 Trip Relays 0 7 1 - F111 1
26EB RRTD 4 - RTD #8 Trip Level 1 200 1 °C F1 130
26EC RRTD 4 - RTD #8 RTD Type 0 3 1 - F120 0
26F0 First Character of RRTD 4 - RTD #8 Name 32 127 1 - F1 ’R’
↓↓
26F3 8th Character of RRTD 4 - RTD #8 Name 32 127 1 - F1 " "
... Reserved
RRTD 4 – RTD #9
2700 RRTD 4 - RTD #9 Application 0 4 1 - F121 0
2701 RRTD 4 - RTD #9 High Alarm 0 2 1 - F115 0
2702 RRTD 4 - RTD #9 High Alarm Relays 0 7 1 - F113 2
2703 RRTD 4 - RTD #9 High Alarm Level 1 200 1 °C F1 130
Table CG–10: MEMORY MAP (Sheet 43 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT

GE 369 Specifications

General

Current Rating	5A
Frequency	50/60 Hz
Mounting	Panel Mount
Protection Functions	Overcurrent, Undervoltage
Type	Digital protective relay
Operating Temperature	-20°C to 60°C
