CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG105
F30
16 Bits DISABLE/ENABLE SELECTION
0Disabled
1Enabled
F31
16 Bits COMMAND FUNCTION CODES
0Not in use
1 Reset 369
2Motor Start
3 Motor Stop
4 Waveform Trigger
5 Reserved
6 Clear Trip Counters
7 Clear Last Trip Data
8 Reserved
9 Reserved
10 Clear RTD Maximums
11 Reset Motor Info
12 Clear/Reset all Data
20 Block/Unblock Protection Functions
21 Force Output Relays
F85
Unsigned 16 bit integer WAVEFORM CAPTURE TRIGGER CAUSE
0None
1Manual
2Automatic
F100
Unsigned 16 bit integer TEMPERATURE DISPLAY UNITS
0Celsius
1Fahrenheit
F101
Unsigned 16 bit integer BAUD RATE
0 1200 baud
1 2400 baud
2 4800 baud
3 9600 baud
4 19200 baud
F102
Unsigned 16 bit integer PARITY
0None
1Odd
2 Even
Table CG–11: Memory Map Data Formats (Sheet 3 of 27)
CODE TYPE DEFINITION
