CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG109
F123
Unsigned 16 bit integer ALARM STATUS
0Off
1Not Active
2 Timing Out
3Active
4Latched
F124
Unsigned 16 bit integer PHASE ROTATION AT MOTOR TERMINALS
0ABC
1ACB
F125
Unsigned 16 bit integer STARTER TYPE
0Breaker
1 Contactor
Table CG–11: Memory Map Data Formats (Sheet 7 of 27)
