CG64 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
15AE Select Curve Style 0 1 1 - F128 0
O/L CURVE SETUP
15AF Standard Overload Curve Number 1 15 1 - F1 4
15B0 Time to Trip at 1.01 x FLA 0 65534 1 s F1 17415
15B2 Time to Trip at 1.05 x FLA 0 65534 1 s F1 3415
15B4 Time to Trip at 1.10 x FLA 0 65534 1 s F1 1667
15B6 Time to Trip at 1.20 x FLA 0 65534 1 s F1 795
15B8 Time to Trip at 1.30 x FLA 0 65534 1 s F1 507
15BA Time to Trip at 1.40 x FLA 0 65534 1 s F1 365
15BC Time to Trip at 1.50 x FLA 0 65534 1 s F1 280
15BE Time to Trip at 1.75 x FLA 0 65534 1 s F1 170
15C0 Time to Trip at 2.00 x FLA 0 65534 1 s F1 117
15C2 Time to Trip at 2.25 x FLA 0 65534 1 s F1 86
15C4 Time to Trip at 2.50 x FLA 0 65534 1 s F1 67
15C6 Time to Trip at 2.75 x FLA 0 65534 1 s F1 53
15C8 Time to Trip at 3.00 x FLA 0 65534 1 s F1 44
15CA Time to Trip at 3.25 x FLA 0 65534 1 s F1 37
15CC Time to Trip at 3.50 x FLA 0 65534 1 s F1 31
15CE Time to Trip at 3.75 x FLA 0 65534 1 s F1 27
15D0 Time to Trip at 4.00 x FLA 0 65534 1 s F1 23
15D2 Time to Trip at 4.25 x FLA 0 65534 1 s F1 21
15D4 Time to Trip at 4.50 x FLA 0 65534 1 s F1 18
15D6 Time to Trip at 4.75 x FLA 0 65534 1 s F1 16
15D8 Time to Trip at 5.00 x FLA 0 65534 1 s F1 15
15DA Time to Trip at 5.50 x FLA 0 65534 1 s F1 12
15DC Time to Trip at 6.00 x FLA 0 65534 1 s F1 10
15DE Time to Trip at 6.50 x FLA 0 65534 1 s F1 9
15E0 Time to Trip at 7.00 x FLA 0 65534 1 s F1 7
15E2 Time to Trip at 7.50 x FLA 0 65534 1 s F1 6
15E4 Time to Trip at 8.00 x FLA 0 65534 1 s F1 6
15E6 Time to Trip at 10.0 x FLA 0 65534 1 s F1 6
15E8 Time to Trip at 15.0 x FLA 0 65534 1 s F1 6
15EA Time to Trip at 20.0 x FLA 0 65534 1 s F1 6
... Reserved
SHORT CIRCUIT TRIP (0 = INSTANTANEOUS TIME DELAY)
1640 Short Circuit Trip 0 1 1 - F115 0
1641 Reserved
1642 Assign Short Circuit Trip Relays 0 7 1 - F111 1
1643 Short Circuit Trip Level 20 200 1 × CT F2 100
1644 Short Circuit Trip Delay 0 255.00 0.01 s F3 0
1645 Short Circuit Trip Backup 0 2 1 - F115 0
1646 Assign Short Circuit Backup Relays 0 3 1 - F119 1
1647 Add Short Circuit Trip Backup Delay 0 25500 0.01 s F3 20
... Reserved
OVERLOAD ALARM
1650 Overload Alarm 0 2 1 - F115 0
1651 Overload Alarm Level 101 150 1 0.01 × FLA F3 101
1652 Assign Overload Alarm Relays 0 7 1 - F113 1
1653 Overload Alarm Delay 0 600 1 s F2 10
1654 Overload Alarm Events 0 1 1 - F103 0
... Reserved
MECHANICAL JAM
1660 Mechanical Jam Alarm 0 2 1 - F115 0
1661 Assign Alarm Relays 0 7 1 - F113 1
1662 Mechanical Jam Alarm Level 101 600 1 0.01 × FLA F3 150
1663 Mechanical Jam Alarm Delay 5 1250 5 s F2 10
1664 Mechanical Jam Alarm Events 0 1 1 - F103 0
1665 Mechanical Jam Trip 0 2 1 - F115 0
1666 Assign Trip Relays 0 7 1 - F111 1
Table CG–10: MEMORY MAP (Sheet 19 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
