CG78 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
RRTD 1 – RTD #11
2140 RRTD 1 - RTD #11 Application 0 4 1 - F121 0
2141 RRTD 1 - RTD #11 High Alarm 0 2 1 - F115 0
2142 RRTD 1 - RTD #11 High Alarm Relays 0 7 1 - F113 2
2143 RRTD 1 - RTD #11 High Alarm Level 1 200 1 °C F1 130
2144 RRTD 1 - RTD #11 Alarm 0 2 1 - F115 0
2145 RRTD 1 - RTD #11 Alarm Relays 0 7 1 - F113 1
2146 RRTD 1 - RTD #11 Alarm Level 1 200 1 °C F1 130
2147
Record RRTD 1 - RTD #11 Alarms as
Events
0 1 1 - F103 0
2148 RRTD 1 - RTD #11 Trip 0 2 1 - F115 0
2149 Enable RRTD 1 - RTD #11 Trip Voting 0 13 1 - F122 1
214A RRTD 1 - RTD #11 Trip Relays 0 7 1 - F111 1
214B RRTD 1 - RTD #11 Trip Level 1 200 1 °C F1 130
214C RRTD 1 - RTD #11 RTD Type 0 3 1 - F120 0
2150 First Character of RRTD 1 - RTD #11 Name 32 127 1 - F1 ’R’
↓↓
2153 8th Character of RRTD 1 - RTD #11 Name 32 127 1 - F1 " "
... Reserved
RRTD 1 – RTD #12
2160 RRTD 1 - RTD #12 Application 0 4 1 - F121 0
2161 RRTD 1 - RTD #12 High Alarm 0 2 1 - F115 0
2162 RRTD 1 - RTD #12 High Alarm Relays 0 7 1 - F113 2
2163 RRTD 1 - RTD #12 High Alarm Level 1 200 1 °C F1 130
2164 RRTD 1 - RTD #12 Alarm 0 2 1 - F115 0
2165 RRTD 1 - RTD #12 Alarm Relays 0 7 1 - F113 1
2166 RRTD 1 - RTD #12 Alarm Level 1 200 1 °C F1 130
2167
Record RRTD 1 - RTD #12 Alarms as
Events
0 1 1 - F103 0
2168 RRTD 1 - RTD #12 Trip 0 2 1 - F115 0
2169 Enable RRTD 1 - RTD #12 Trip Voting 0 13 1 - F122 1
216A RRTD 1 - RTD #12 Trip Relays 0 7 1 - F111 1
216B RRTD 1 - RTD #12 Trip Level 1 200 1 °C F1 130
216C RRTD 1 - RTD #12 RTD Type 0 3 1 - F120 0
2170 First Character of RRTD 1 - RTD #12 Name 32 127 1 - F1 ’R’
↓↓
2173 8th Character of RRTD 1 - RTD #12 Name 32 127 1 - F1 " "
... Reserved
RRTD 1 – OPEN RTD ALARM
2180 RRTD A - Open RTD Alarm 0 2 1 - F115 0
2181 RRTD A - Assign Alarm Relays 0 7 1 - F113 1
2182 RRTD A - Open RTD Alarm Events 0 1 1 - F103 0
RRTD 1 – SHORT/LOW TEMPERATURE RTD ALARM
2183 RRTD A - Short / Low Temp RTD Alarm 0 2 1 - F115 0
2184 RRTD A - Assign Alarm Relays 0 7 1 - F113 1
2185 RRTD A - Short / Low Temp Alarm Events 0 1 1 - F103 0
... Reserved - - - - - -
RRTD 2 – RTD #1
2200 RRTD 2 - RTD #1 Application 0 4 1 - F121 0
2201 RRTD 2 - RTD #1 High Alarm 0 2 1 - F115 0
2202 RRTD 2 - RTD #1 High Alarm Relays 0 7 1 - F113 2
2203 RRTD 2 - RTD #1 High Alarm Level 1 200 1 °C F1 130
2204 RRTD 2 - RTD #1 Alarm 0 2 1 - F115 0
2205 RRTD 2 - RTD #1 Alarm Relays 0 7 1 - F113 1
2206 RRTD 2 - RTD #1 Alarm Level 1 200 1 °C F1 130
2207 Record RRTD 2 - RTD #1 Alarms as Events 0 1 1 - F103 0
2208 RRTD 2 - RTD #1 Trip 0 2 1 - F115 0
2209 Enable RRTD 2 - RTD #1 Trip Voting 0 13 1 - F122 1
220A RRTD 2 - RTD #1 Trip Relays 0 7 1 - F111 1
220B RRTD 2 - RTD #1 Trip Level 1 200 1 °C F1 130
Table CG–10: MEMORY MAP (Sheet 33 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
