CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG95
↓↓
2985
11th & 12th Character of Digital Input 1
Name
32 127 1 - F22 ’GE’
2990 Digital Input 1 Type 0 1 1 - F116 0
2991 Reserved
2992 Digital Input 1 Alarm 0 2 1 - F115 0
2993 Digital Input 1 Alarm Relays 0 6 1 - F113 0
2994 Digital Input 1 Alarm Delay 1 50000 1 100ms F2 50
2995 Digital Input 1 Alarm Events 0 1 1 - F103 0
2996 Digital Input 1 Trip 0 2 1 - F115 0
2997 Digital Input 1 Trip Relays 0 6 1 - F111 0
2998 Digital Input 1 Trip Delay 1 50000 1 100ms F2 50
2999 Digital Input 1 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 2 – DIGITAL INPUT 6
29A0
1st & 2nd Character of Digital Input 6
Name
32 127 1 - F22 ’GE’
↓↓
29A5
11th & 12th Character of Digital Input 6
Name
32 127 1 - F22 ’GE’
29B0 Digital Input 6 Type 0 1 1 - F116 0
29B1 Reserved
29B2 Digital Input 6 Alarm 0 2 1 - F115 0
29B3 Digital Input 6 Alarm Relays 0 6 1 - F113 0
29B4 Digital Input 6 Alarm Delay 1 50000 1 100ms F2 50
29B5 Digital Input 6 Alarm Events 0 1 1 - F103 0
29B6 Digital Input 6 Trip 0 2 1 - F115 0
29B7 Digital Input 6 Trip Relays 0 6 1 - F111 0
29B8 Digital Input 6 Trip Delay 1 50000 1 100ms F2 50
29B9 Digital Input 6 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 2 – DIGITAL INPUT 3
29C0
1st & 2nd Character of Digital Input 3
Name
32 127 1 - F22 ’GE’
↓↓
29C5
11th & 12th Character of Digital Input 3
Name
32 127 1 - F22 ’GE’
29D0 Digital Input 3 Type 0 1 1 - F116 0
29D1 Reserved
29D2 Digital Input 3 Alarm 0 2 1 - F115 0
29D3 Digital Input 3 Alarm Relays 0 6 1 - F113 0
29D4 Digital Input 3 Alarm Delay 1 50000 1 100ms F2 50
29D5 Digital Input 3 Alarm Events 0 1 1 - F103 0
29D6 Digital Input 3 Trip 0 2 1 - F115 0
29D7 Digital Input 3 Trip Relays 0 6 1 - F111 0
29D8 Digital Input 3 Trip Delay 1 50000 1 100ms F2 50
29D9 Digital Input 3 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 3 – DIGITAL INPUT 2
29E0
1st & 2nd Character of Digital Input 2
Name
32 127 1 - F22 ’GE’
↓↓
29E5
11th & 12th Character of Digital Input 2
Name
32 127 1 - F22 ’GE’
29F0 Digital Input 2 Type 0 1 1 - F116 0
29F1 Reserved
29F2 Digital Input 2 Alarm 0 2 1 - F115 0
29F3 Digital Input 2 Alarm Relays 0 6 1 - F113 0
29F4 Digital Input 2 Alarm Delay 1 50000 1 100ms F2 50
29F5 Digital Input 2 Alarm Events 0 1 1 - F103 0
29F6 Digital Input 2 Trip 0 2 1 - F115 0
29F7 Digital Input 2 Trip Relays 0 6 1 - F111 0
Table CG–10: MEMORY MAP (Sheet 50 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
