TRANSPORT MOUNTING PANEL
KIT CONTENTS
The Transport Mounting Plate kit (VersaMed Part Number 900K0015-01, GE Part
Number M1169908) includes:
ITEM NO. DESCRIPTION DIMENSIONS QUANTITY
1
Transport Mounting plate 305.5 x 117mm 1
2
Screws M3 x 10mm 4
3 Flat washers 4
4 Spring washers 4
5 Spacers (for Disaster
Preparedness devices only)
M3x10mm 4
INSTALLATION
1. Turn off the ventilator and disconnect the power cable and patient circuit
tubing from it.
2. Flip the ventilator upside-down.
Note: If an old model with an old mounting plate (VersaMed P/N. 325A0162-A3,
GE P/N. M1161827) is attached to the ventilator, release the 4 screws that hold
the old model of the Mounting plate, and remove it (See Figure 190).
3. For Disaster Preparedness models only: Screw the four spacers (item no. 5) into
place, using a #6mm socket wrench (See Figure 191).
4. Lay the Transport mounting plate (item no. 1) on the ventilator (see Figure 192).
5. Place a spring washer (item no. 4) and flat washer (item no. 3) on each of the
screw holes on the plate (See Figure 193).
6. Insert a screw (item no. 2) into each of the screw holes, and screw the four
Philips screws with a Philips screwdriver.
7. Stand the ventilator upright (standing on the Transport mounting plate).
