4 IMPLEMENTATION
Electrical InterMiCOM is configured using a combination of settings in the INTERMICOM COMMS column, settings in
the INTERMICOM CONF column, and the programmable scheme logic (PSL).
The eight command signals are mapped to DDB signals within the product using the PSL.
Signals being sent to a remote terminal are referenced in the PSL as IM Output 1 - IM Output 8. Signals received
from the remote terminal are referenced as IM Input 1 - IM Input 8.
Note:
As well as the optional Modem InterMiCOM, some products are available with a feature called InterMiCOM64 (IM64). The
functionality and assignment of commands in InterMiCOM and InterMiCOM64 are similar, but they act independently and are
configured independently.
