Basic scanning operations
122 Vivid S5/Vivid S6 User Manual
R2424458-100 Rev. 2
Physiological trace
The physiological module consists of a single connector, which
can accept either a set of electrodes cable or an External-ECG
cable, capable of handling external ECG signals from other
diagnostic ECG devices.
The scanned image that is displayed is synchronized with the
ECG trace. In M-Mode or Doppler, the traces are synchronized
to that particular mode's sweep.
The operator can control the gain, the position and the sweep
rate of the traces using the assignables on the control panel.
Connecting the internal ECG
The ECG cable is a modular cable consisting of two different
cables parts:
• The Trunk: a single cable connecting to the system at one
end, and providing a cable splitter device at the other end.
• The triple color-coded electrode cable: to be inserted in
the splitter device. Each electrode cable hooks up to the
appropriate stick-on electrode by a color-coded clip type
connector.
The color-coding of the electrodes follows one of two standards
that are common in different parts of the world. The cable
splitter device has a drawing defining the color codes, names
and body location for the two standard color codes. Refer to the
Table 3-1.
CAUTION
Use only GE Medical Systems accessories Conductive parts of
electrodes and associated connectors for applied parts,
including neutral electrodes should not contact other conductive
parts, including earth.
Simultaneous use of two or more applied parts will cause
summation of patient leakage currents.
