Quantitative Analysis
400 Vivid S5/Vivid S6 User Manual
R2424458-100 Rev. 2
Figure 8-8: The anatomical M-Mode display (here TVI data)
1. Cineloop window
2. Analysis window
3. Path anchor point
4. Time scale
2
3
4
1
3
