Presets and System setup
Vivid S5/Vivid S6 User Manual 599
R2424458-100 Rev. 2
Parameter Description
Add measurement:
Create or select from the pop-up list a
measurement to be added to a folder (see
page 339).
Add folder:
Enables the user to create its own folder
with the desired measurements. The
folder is displayed the Measurement
menu.
M&A Categories:
Enables selection of the measurement
categories to display in the Measurement
menu. Only checked items will be
displayed.
• Create Copy: Enables copy of a
selected measurement category
(selection is done by selecting the
category name).
• Delete: enables deletion of user-defined
measurement categories.
• Factory Default: restores factory
display.
2D, MM and Dop. radio buttons:
Enables the display of mode related
Measurement menu in the configuration
window.
Configuration tools:
Deletes selected entry (folder or
measurement) in the Measurement
menu. The factory entries cannot be
deleted.
Moves selected measurement or
folder up or down inside the
Measurement menu.
