D
IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
Chapter 5 - Components and Function (Theory) 5-5
PRELIMINARY
5-3-1 User Interface Section
The User Interface section comprises the following modules:
• Operator panel and Speakers
• Main Display
• Touch Screen
• Optional Alphanumeric Keyboard
NOTE: For details, see Top Console with Monitor, Operator Control Panel and Touch Screen on page 5 - 16
5-3-2 Main Scanner Section
The Main Scanner section comprises the Scanner Electronic Cage, that includes the following modules:
• Front End Unit
• Back End Unit
• Patient I/O Module
• Sub-Woofer
• Rear Interface Panel
• Optional DVD-RW
• Optional B/W Printer
NOTE: For an explanation and illustrations of the Electronic Cage, see Vivid™ S60/Vivid™ S70 Ultrasound
Scanner - Electronic Cage on page 5 - 11.
For detailed information on individual modules, refer to the following:
- Front End Unit on page 5 - 21
- Back End Unit on page 5 - 24
- Patient I/O Module on page 5 - 23
5-3-3 Power Supply Section
The Power Supply section comprises the following modules:
• Main AC/DC 18v supply
• B/W Printer AC power control
• Battery Charger
• Optional Battery
NOTE: For details, see System Power Distribution on page 5 - 25.
