D
IRECTION
FR091521, R
EVISION
1
V
IVID
S60N/V
IVID
S70N
B
ASIC
S
ERVICE
M
ANUAL
Chapter 8 - Re
placement Pr
ocedures
8-149
PRELIMINARY
8-6-4-5
Touch Screen Chassis Installation
Procedure.
1.)
Using the replacement Touch Screen Chassis,
perfor
m the procedures previo
usly described in
reverse se
qu
ence.
2.)
Secure cables
with ne
w tie wraps.
3.)
Turn ON power to the Vivid™ S60/Vivid™ S70 ultr
asound scanner.
378
380
