D
IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
1-18 Section 1-1 - Overview
PRELIMINARY
Section 1-7
Product Labels and Icons
The Vivid™ S60N/Vivid™ S70N ultrasound scanner comes equipped with product labels and icons.
These represent pertinent information regarding the operation of the unit.
1-7-1 Universal Product Labels
NOTE: The following diagrams illustrate the labels found on the Vivid S60N/Vivid S70N ultrasound unit. For an
explanation of label icons and symbols, refer to Table 1-7 on page 1-20.
1-7-1-1 System Rating Label
A system Rating Label (examples shown in Table 1-5 , below) is located at the rear of the system. This
indicates the ultrasound unit’s basic power compliance.
Table 1-5 Rating Label
Item # Description Illustration
1.
Rating Label - Vivid™ S60N (100-240V)
International
2.
Rating Label - Vivid™ S70N (100-240V)
International
