D
IRECTION
FR091521, R
EVISION
1
V
IVID
S60N/V
IVID
S70N
B
ASIC
S
ERVICE
M
ANUAL
Chapter 9 - Ren
ewal Parts
9-15
PRELIMINARY
Figure 9-12 Front End Unit - Diag
ram 2
T
able 9-16 Front End Unit - Diagram 2
Item
Part Name
Part Number
Can
Replace
Part #
Can Be
Replaced
by Part #
Not
Compatible
With
Repl
Proc
704
FEPS - Front End Power Supply module
S5409449
705
Release Arm for CFE
S5430823
706
Plasti
c Air sle
eve fo
r CFE
S5422608
704
705
706
Rear View
Front View
RP
RP
RP
434
436
