July 2010 11 – 145
D 756 Programmed rotational speed or rotational speed from the
PLC [0.001 min
–1
]
NC/PLC NC/PLC
D 760 Offset in tilting axes touch probe center offset [1/10 000°] PLC PLC
W 764 Percentage for spindle override (PLC to NC) NC/PLC NC/PLC
W 766 Percentage for feed-rate override (PLC to NC) NC/PLC NC/PLC
D 768 - 956 Value from MP4210.0 to MP4210.47 NC NC
W 960 - 968 Value from MP4220.0 to MP4220.4 NC NC
W 976 - 994 Value from MP4310.0 to MP4310.9 NC NC
W 1002 Last PLC run-time error that occurred NC NC
W 1008 S code for minimum speed NC NC
W 1016 PLC module that was last processed erroneously NC NC
W 1018 Number of files opened by the PLC NC NC
W 1020 Number of all open files NC NC
W 1022 Error status of the last called PLC module NC NC
W 1024 Axis enabling NC NC
W 1026 Axes in position NC NC
W 1028 Axes in motion NC NC
W 1030 Current direction of traverse NC NC
W 1032 Reference marks not yet traversed NC NC
W 1034 Positive software limit switch was approached NC NC
W 1036 Negative software limit switch was approached NC NC
W 1038 Prepare to open the position control loop PLC PLC
W 1040 Axis-specific opening of the position control loop PLC PLC
W 1042 Deactivation of monitoring functions PLC PLC
W 1044 Actual-to-nominal value transfer PLC PLC
W 1046 Manual traverse in positive direction PLC PLC
W 1048 Manual traverse in negative direction PLC PLC
W 1054 Reference end position PLC PLC
W 1056 Lubrication pulse: Value in MP4050.x exceeded NC NC
W 1058 Reset the accumulated distance PLC PLC
W 1060 Axis-specific feed rate enable PLC PLC
W 1062 Lock the handwheel for specific axes PLC PLC
Operand Description Set Reset As of SW vers.
