HEIDENHAIN ITNC 530 Service Manual

July 2010 18 – 287
18.1.7 Determining the field angle on linear motors, torque motors and synchronous spindles
If an encoder was replaced that is also used to control a linear or torque motor or a synchronous
spindle, the commutation (position of the field angle) needs to be reset for this motor.
Caution
The method to define the field angle of the respective axis / spindle is defined by the
machine manufacturer.
Follow the instructions of the machine manufacturer!

HEIDENHAIN ITNC 530 Specifications

General

Control Type	CNC
Look-ahead	Yes
Spindle control	Yes
Touch probe cycles	Yes
Operating voltage	24 V DC
Programming	Conversational and DIN/ISO programming
Interpolation	Linear, Circular, Helical
Data Interface	Ethernet, USB, RS-232
Memory	1 GB
Programming Language	HEIDENHAIN plain language
Operating Modes	Manual, Automatic, MDA
Software Options	Various software options available
