HEIDENHAIN ITNC 530 Service Manual

July 2010 18 – 297
Flowchart
No
Yes
The defect is probably located in the speed
encoder input of the control.
Shut down the control and switch off the
main switch of the machine.
Switch on the main switch of the machine.
The defect is located in the
speed encoder (motor encoder)
or in the encoder cable.
Do not confirm the Power interrupted message
but immediately call the MP list.
Interchange the input values of the axes
concerned in MP 112.x. (In the example:
MP 112.0: 16 und MP 112.1: 15)
Label the cables of the speed encoders and
interchange them on the CC 422.
(In the example: connectors X15 and X16)
Does the error pattern
move to the other axis?
(In the example:
from X to Y)
Interchanging the motor encoder inputs
on the CC 422
Switch on the machine and traverse the axes.
Deactivate the evaluation of the electronic
ID labels before interchanging the speed
encoder inputs.
For every bit enter the value 1 in MP 7690.
Set MP 7690 (evaluation of the electronic
ID labels) to the original value.

HEIDENHAIN ITNC 530 Specifications

General

Control Type	CNC
Look-ahead	Yes
Spindle control	Yes
Touch probe cycles	Yes
Operating voltage	24 V DC
Programming	Conversational and DIN/ISO programming
Interpolation	Linear, Circular, Helical
Data Interface	Ethernet, USB, RS-232
Memory	1 GB
Programming Language	HEIDENHAIN plain language
Operating Modes	Manual, Automatic, MDA
Software Options	Various software options available
