30 R2 30 WH/GY 30 30
31 R3 31 White/Blue 31 31
32 0 V 32 Gray/Violet 32 32
33 G0
33 Brown/Violet 33 33
34 G1 34 Green/Violet 34 34
35 G2
35 Orange/Violet 35 35
36 G3
36 Blue/Violet 36 36
37 0 V 37 Gray/Red 37 37
38 B0
38 Brown/Red 38 38
39 B1
39 Gray/Yellow 39 39
40 B2 40 Brown/Yellow 40 40
41 B3
41 Green/Yellow 41 41
42 0 V 42 Vacant 42 42
43 DISP.
LOW
43 Red/Blue 43 43
44 DISP.
LOW
44 Blue/Red 44 44
45 DISP.ON
45 Red/Orange 45 45
46 DISP.ON 46 Orange/Red 46 46
47 C0 47 Green/Red 47 47
48 C1 48 Red/Green 48 48
49 C2 49 Orange/Yellow 49 49
50 C3 50 Yellow/Orange 50 50
51 C4 51 Yellow/Blue 51 51
52 C5 52 Blue/Yellow 52 52
53 to 56 Do not assign 53 to 56 Vacant 53 to 56 53 to 56
57 to 62 0 V 57 to 62 Vacant 57 to 62 57 to 62
Housing Housing Housing Housing
MC 42x(B/C), X49 Connecting cable ID 340 300-xx BF 120, X2
Female Assignment Male Female Male
Note
The interface complies with the requirements of EN 61800-5-1 for "protective extra-low
voltage" (PELV).
DANGER
Only units that comply with the requirements of EN 61800-5-1 for "protective extra-low
voltage" (PELV) may be connected.

HEIDENHAIN ITNC 530 Specifications

General

Control Type	CNC
Look-ahead	Yes
Spindle control	Yes
Touch probe cycles	Yes
Operating voltage	24 V DC
Programming	Conversational and DIN/ISO programming
Interpolation	Linear, Circular, Helical
Data Interface	Ethernet, USB, RS-232
Memory	1 GB
Programming Language	HEIDENHAIN plain language
Operating Modes	Manual, Automatic, MDA
Software Options	Various software options available
