July 2010 30 – 577
Activate the
modified values
After you have modified parameter values for service purposes:
8 Place the cursor after the last modified parameter in the next line. -->
The MP list is structured completely.
8 Exit the machine parameter list by pressing the END key.
Missing or incorrect entries result in error messages from the control that prompt you to correct
your entry.
The following errors are displayed:
If the control does not recognize any errors, it automatically exits the machine parameter editor
and is ready for operation after a defined reaction.
Reaction to change If parameter values were changed and confirmed with END, the control can react as follows:
Modified values are immediately confirmed without reset and new referencing (e.g., when
changing color settings).
Axes must be referenced anew (e.g., when changing axis parameters).
A reset is started (e.g., when changing certain control-loop parameters).
Operating the
machine with the
new values
If the machine manufacturer agrees that the machine should be operated with the new
settings...
8 Transmit the changed parameter values in the original MP list (or activate an agreed MP list),
write your name (or owner's name) and modification date as a comment into the header of the
list.
8 Create a new backup of the machine data. --> See “Backup on an External Data Medium”
on page 13 – 192.
Input error Meaning
0 No MP number found
1 Invalid MP number
2 No separator (:) found
3 Entry value incorrect
4 MP defined twice
6 MP cannot be stored
Most machine parameters cannot be stored while an NC program is running.
The error message Parallel operation not possible appears.
The program must be stopped and exited. Then the modified data can be saved.
This behavior is defined by HEIDENHAIN and cannot be influenced!
If you have reason to doubt that a changed parameter was transferred or not, the control can
be rebooted manually.
