30 – 584 HEIDENHAIN Service Manual iTNC 530
MP750.x Reversal error (backlash compensation)
Input: -9.9999 to +9.9999 [mm] or [°]
PLC
RUN
340 490-04
MP752.x Compensation time for reversal error
Input: 0 to 1000 [ms]
PLC
RUN
MP810.x Display mode for rotary axes and PLC auxiliary axes
Input: 0.0000 to 99 999.9999 [°]
0: Display +/–99 999.9999
1: Modulo value for display
PLC
RUN
REF
MP812 Activate software limit switches for tilting axes with modulo display, M94 and encoders
with EnDat interface
Format: %xxxxxxxxxxxxxx
Input: Bits 0 to 13 represent axes 1 to 14
0: Software limit switch not active
1: Software limit switch active
RESET
MP850.x Synchronized axes
Input:
0: Master axis
1: Slave axis to axis 1
2: Slave axis to axis 2
3: Slave axis to axis 3
4: Slave axis to axis 4
5: Slave axis to axis 5
6: Slave axis to axis 6
7: Slave axis to axis 7
8: Slave axis to axis 8
9: Slave axis to axis 9
PLC
RUN
MP855.x Synchronization monitoring
Input: 0 to 100,0000 [mm]
0: Monitoring not active
PLC
RUN
MP860.x Datum for synchronous control
Input: 0: Datum at position after switch-on
1: Datum at reference marks
2: Axis is torque slave axis
PLC
RUN
MP910.x Positive software limit switches, traverse range 1 (default setting after power on)
Input: -99 999.9999 to +99 999.9999 [mm] or [°]
PLC
RUN
MP911.x Positive software limit switches, traverse range 2
Input: -99 999.9999 to +99 999.9999 [mm] or [°]
PLC
RUN
MP912.x Positive software limit switches, traverse range 3
Input: -99 999.9999 to +99 999.9999 [mm] or [°]
PLC
RUN
MP920.x Negative software limit switches, traverse range 1 (default setting after power on)
Input: -99 999.9999 to +99 999.9999 [mm] or [°]
PLC
RUN
MP921.x Negative software limit switches, traverse range 2
Input: -99 999.9999 to +99 999.9999 [mm] or [°]
PLC
RUN
MP922.x Negative software limit switches, traverse range 3
Input: -99 999.9999 to +99 999.9999 [mm] or [°]
PLC
RUN
MP950.x Datum for positioning blocks with M92 for axes 1 to 9
Input: -99 999.9999 to +99 999.9999 [mm] or [°]
Values with respect to the machine datum
PLC
RUN
