OPERA
T
OR'S ST
A
TION
1-79
W
ork Light Switch
Pr
ess the mark
on switch (1) while the light switch is in
"
" or "
" position to turn fr
ont work lights (2) ON.
Rear work lights (3) stay OFF
.
When the side with mark
on switch (1) is pressed
, all
front work lights (2), r
ear work lights (3), and rear cab lights
(4) turn ON.
d
CAUTION:
Do not turn the work lights ON while
driving on a public road.
1
MNF
A-01-011
MNEC-01-037
1
2
2
MNEC-01-523
4
3
4
3
MNEK-01-06US
140
142
