MAINTENANCE
7-113
Check and Adjust
Valv
e Clearanc
e
--- every 5000 hours
Consult your near
est authorized dealer for check and repair
.
Retighten F
ront Axle and Rear Axle Support
Mounting Bolts
--- every 2000 hours (50 hours at first time only)
Check front and rear axle support mounting bolts for
looseness.
Tigh
tening torques of the front axle and r
ear axle
support mounting bolts
F
ront Axle Mounting Bolt
Rear Axle Suppor
t Mounting
Bolt
785±150 N·m
(579±111 lbf·ft)
890±170 N·m (656±125 lbf·ft)
