7-12
MAINTENANCE
Rear Grille
d
CAUTION:
Open or close rear grille (2) only after stopping
the engine. Failure to do so may create a very
dangerous situation as entanglement with the
cooling fan may result.
Before driving the machine, always check that
rear grille (2) is not open.
Rear grille (2) may spring open. Take care not to
come in contact with the rear grille.
Opening the rear grille
Push open/close Button (1) laterally to open rear grille
(2) upward, allowing the fuel tank to be refilled and/or
the cooling fan to be cleaned.
Closing the rear grille
While holding the rear grille, slowly close the rear grille
downward until a "click" sound is heard.
1
2
MNEK-01-021
MNEK-01-020
