Juniper EX4500 Series User Manual

Uplink Modules
Optional uplink modules are available for EX4500 switches. Two uplink modules can
be installed in an EX4500 switch. Each uplink module provides four SFP+ ports for
connecting to core devices in a data center. You can install SFP or SFP+ transceivers
in these ports.
Related Topics EX4500 Switch Models on page 5■
■ Field-Replaceable Units in EX4500 Switches on page 14
EX4500 Switch Models
The EX4500 switch is available in two models—one with front-to-back airflow and
the other with back-to-front airflow. Table 1 on page 5 lists the two models for an
EX4500 switch and the components included in each model.
NOTE: The side of the switch where the network ports are located is the front of the
switch.
Table 1: EX4500 Switch Models and Their Components
Switch ComponentsDirection of Airflow
Access Port
ConfigurationModel
■
Chassis
■
One fan tray (with green exhaust label visible)
■
One AC power supply (with green ejector lever)
■
One power cord
■
One power supply cover panel
■
Two uplink module cover panels
■
One intraconnect module
Front-to-back40-port GbE/10GbE
SFP/SFP+
EX4500-40F-FB
■
Chassis
■
One fan tray (with orange intake label visible)
■
One AC power supply (with orange ejector
lever)
■
One power cord
■
One power supply cover panel
■
Two uplink module cover panels
■
One intraconnect module
Back-to-front40-port GbE/10GbE
SFP/SFP+
EX4500-40F-BF
EX4500 Switch Models ■ 5
Chapter 1: EX4500 Switch Overview
