■ Cabinet Requirements for EX4500 Switches on page 50
■ Clearance Requirements for Airflow and Hardware Maintenance for EX4500
Switches on page 52
Unpacking an EX4500 Switch
The EX4500 switches are shipped in a cardboard carton, secured with foam packing
material. The carton has an accessory compartment and contains the quick start
instructions.
CAUTION: EX4500 switches are maximally protected inside the shipping carton. Do
not unpack the switches until you are ready to begin installation.
To unpack the switch:
1. Open the carton.
2. Pull out the packing material holding the switch in place.
3. Verify the parts received against the inventory on the label attached to the carton
and listed in Table 25 on page 64.
4. Save the shipping carton and packing materials in case you need to move or
ship the switch later.
Table 25: Inventory of Components Provided with an EX4500 Switch
QuantityComponent
1Switch
1Fan tray (preinstalled)
1 ACPower supply (preinstalled )
1AC power cord appropriate for your geographical location
1Power cord retainer clip
■
Power supply cover panel: 1
■
Uplink module cover panels: 2
Cover panels for slots without installed components
40Dust covers for ports
2Mounting brackets
20Mounting screws
4Rubber feet
64 ■ Unpacking an EX4500 Switch
Complete Hardware Guide for EX4500 Ethernet Switches
