Management Port Connector Pinout Information for an EX4500 Switch
The management port on an EX4500 switch uses an RJ-45 connector to connect to
a management device for out-of-band management.
The port uses an autosensing RJ-45 connector to support a 10/100/1000Base-T
connection. Two LEDs on the port indicate link/activity on the port and the
administrative status of the port. See “Management Port LEDs in EX4500 Switches”
on page 17.
Table 13 on page 29 provides the pinout information for the RJ-45 connector for the
management port. An RJ-45 cable, with a connector attached, is supplied with the
switch.
Table 13: Management Port Connector Pinout Information for EX4500 Switches
DescriptionSignalPin
Transmit/receive data pair 1TRP1+1
Transmit/receive data pair 1TRP1-2
Transmit/receive data pair 2TRP2+3
Transmit/receive data pair 3TRP3+4
Transmit/receive data pair 3TRP3-5
Transmit/receive data pair 2TRP2-6
Transmit/receive data pair 4TRP4+7
Transmit/receive data pair 4TRP4-8
Related Topics See Front Panel of an EX4500 Switch on page 7 for port location.■
■ Connecting an EX Series Switch to a Network for Out-of-Band Management on
page 91
Management Port Connector Pinout Information for an EX4500 Switch ■ 29
