JNP10K-PWR-AC Power Supply | 61
JNP10K-PWR-AC Power Supply LEDs | 70
MX10000 Power Cables Specifications | 107
JNP10K-PWR-AC2 Power Specifications
MX10008 and MX10016 redundant configuration router can use either AC or DC power supplies; base
configuration routers are AC only. The JNP10K-PWR-AC2 power supply supports AC, HVAC, and HVDC.
Table 37 on page 106 lists the power specifications for the AC power supply (JNP10K-PWR-AC) used in
an MX10000 chassis.
Table 37: Power Specifications for a JNP10K-PWR-AC2 Power Supply
SpecificationsItem
180–305 VACAC input voltage
190–410 VDCDC input voltage
28.5 AInput current rating
12.3 V, 5500 W with dual feed and 5000 W with single feedDC output power
Table 38 on page 106 shows the physical specifications for a JNP10K-PWR-AC2 power supply.
Table 38: Physical Specifications for a JNP10K-PWR-AC2 Power Supply
ValueSpecification
3.5 in. (8.89 cm)Height
3.6 in. (9.14 cm)Width
15.1 in. (38.35 cm)Depth
12.2 lb (5.53 kg)Weight
106
