Juniper MX10008 User Manual

Table 48: Console Port Connector Pinouts for the MX10008 Router (continued)
DescriptionSignalPin
Transmit dataTxD Output3
Signal groundSignal Ground4
Signal groundSignal Ground5
Receive dataRxD Input6
Data carrier detect
Time of day for PTP. You can use DCD
pins as a TOD UART by using breakout
cables.
DCD Input
TOD Output for PTP applications
7
Clear to sendCTS Input8
SEE ALSO
Connecting an MX10008 Router to a Management Console | 166
USB Port Specifications for the MX10008 Router
The following Juniper Networks USB flash drives have been tested and are officially supported for the
USB port in the MX10008 router:
•
RE-USB-1G-S—1-gigabyte (GB) USB flash drive
•
RE-USB-2G-S—2-GB USB flash drive
•
RE-USB-4G-S—4-GB USB flash drive
126
